Specifications
Brand Name :
MTL
Model Number :
SD32
Place of Origin :
India
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T,Western Union
Supply Ability :
500pcs/month
Delivery Time :
ship out immediately after payment received
Packaging Details :
original package
Condition :
MTL original brand new
Warranty :
one year
Series :
Eaton Crouse-Hinds series
Shipping way :
DHL FedEx express
Application :
Automation Industries, oil, gas, chemical industries
Certificate :
CE ISO TUV
Description

SD32 MTLSD32 EATON Surge Protection Device MTL Surge Arrestor


Eaton Crouse-Hinds series MTL SD surge protector, 22 Vac, 32 Vdc, 5kA surge current, 250mA, T-section DIN rail, <45V voltage protection level, Fuse disconnect, 12 AWG


Product Name
Eaton Crouse-Hinds series MTL SD surge protector
Product Name
Eaton Crouse-Hinds series MTL SD surge protector
Catalog Number
SD32
Product Length/Depth
99 mm
Product Height
101.3 mm
Product Width
7 mm
Product Weight
70 g
Global Catalog
SD32
Product Type
Surge protector
Area classification
Hazardous/Classified Locations
Standards type
IECEx/ATEX
NEC/CEC
IEC
IECEx/ATEX hazardous rating
Zone 2
Ingress protection (IP) ratings
IP54
Mounting Method
T-section DIN rail
Frequency
25 kHz
Response Time
<1ns
Fuse Disconnect
Yes
Category Tested Acc. IEC 61643-21
A2, B2, C1, C2, C3, D1
Conductor Cross-section AWG
12 AWG
Minimum Ambient Operating Temperature
-40 °C
Maximum Ambient Operating Temperature
80 °C
Minimum Ambient Storage Temperature
-40 °C
Maximum Ambient Storage Temperature
80 °C
Humidity
5-95% RH (non-condensing)
Modes of Protection
For protecting electronic equipment and systems against surges on signal and I/O cabling
Nominal Voltage AC
22V
Nominal Voltage DC
32V
Nominal Discharge Surge Current (8/20)
5 kA
Lightning Impulse Current (10/350 µs)
2.8 kA
Nominal Load Current
250mA
Voltage Protection Level at In
60V
Voltage Protection Level at 1kV/µS
<45V
Series Resistance (Ω/Line)
4.2Ω
Max. Leakage Current
5µA
Max. Continuous Voltage AC
36V
