IP20 Industrial Servo Drives 0.1KW - 3.8KW AC Servo Motor Drive For Precision Position Control
IP20 Industrial Servo Drives 0.1KW - 3.8KW AC Servo Motor Drive For Precision Position Control
IP20 Industrial Servo Drives 0.1KW - 3.8KW AC Servo Motor Drive For Precision Position Control
IP20 Industrial Servo Drives 0.1KW - 3.8KW AC Servo Motor Drive For Precision Position Control
IP20 Industrial Servo Drives 0.1KW - 3.8KW AC Servo Motor Drive For Precision Position Control
IP20 Industrial Servo Drives 0.1KW - 3.8KW AC Servo Motor Drive For Precision Position Control
IP20 Industrial Servo Drives 0.1KW - 3.8KW AC Servo Motor Drive For Precision Position Control
IP20 Industrial Servo Drives 0.1KW - 3.8KW AC Servo Motor Drive For Precision Position Control
IP20 Industrial Servo Drives 0.1KW - 3.8KW AC Servo Motor Drive For Precision Position Control
IP20 Industrial Servo Drives 0.1KW - 3.8KW AC Servo Motor Drive For Precision Position Control
IP20 Industrial Servo Drives 0.1KW - 3.8KW AC Servo Motor Drive For Precision Position Control
IP20 Industrial Servo Drives 0.1KW - 3.8KW AC Servo Motor Drive For Precision Position Control
Specifications
Brand Name :
WEIDE
Model Number :
130ST-CJ105415L5/1.5kw
Certification :
CE
Place of Origin :
CHINA
MOQ :
1
Price :
210 USD
Payment Terms :
L/C,T/T
Supply Ability :
5000/years
Delivery Time :
15days
Packaging Details :
10.00cm * 6.00cm * 12.00cm 3.5kg
Name :
Industrial Servo Drives
Control Mode :
Position Control
Compatible Feedback Units :
Compatible Feedback Units
Adopts the latest power device IPM :
featuring compact size, strong overload capacity, and high reliability
Optimized brake unit :
suitable for frequent start-stop applications
Simple operation :
Convenient trial run, monitoring, and parameter setting with only 4 keys
Applicable Power Range :
0.1~3.8 KW
Description
Industrial AC Servo Drive with 2500PPR Incremental Encoder PWM Sine Wave Vector Control for Precision Position Control
High-performance servo motor and drive combination designed for precision automation control systems with advanced position control capabilities.
Model Number
130ST-CJ105415L5/1.5kw
Mathematical Model
Linear
Signal Type
Continuous
Function
Automatic Control, Protection
Certifications
CCC, ISO: 9001, CE
Condition
New
Material
Aluminum Alloy
Input Power
Single Phase L1, L2/Three Phase L1, L2, L3 AC220V
Temperature Range
Working: 0~40℃; Storing: -40~50℃
Control Type
PWM Sine Wave Vector Control
Feedback Mode
2500PPR Incremental Encoder
Control Mode
Position
B Series Universal Servo Driver & Motor Features
IP20 Industrial Servo Drives 0.1KW - 3.8KW AC Servo Motor Drive For Precision Position Control
  • Position Control Mode with adaptive feedback unit
  • 2500ppr incremental encoder and wire-saving encoder compatibility
  • Advanced IPM (Intelligent Power Module) for compact size and high reliability
  • Optimized braking unit for frequent start-stop operations
  • User-friendly operation with trial operation, monitoring, and parameter settings via 4 keys
  • Adaptive power range: 0.1~3.8KW
Model Specifications
IP20 Industrial Servo Drives 0.1KW - 3.8KW AC Servo Motor Drive For Precision Position Control
Model No. 10B 15B 20B 30B
Output Power (KW) 0.05-0.4 0.6-1.0 1.0-1.3 1.5-3.8
Rated Torque (N.m) 0.01-1.3 1.9-4 4-10 6-15
Technical Specifications
Input Power: Single Phase L1,L2/Three Phase L1,L2,L3 AC220V-15%~+10%
Temperature: Working: 0~40℃; Storing: -40~50℃
Humidity: Working: 40%~80% (no dew); Storing: below 93% (no dew)
IP Grade: IP20
Control Mode: PWM sine wave vector control
Regenerative Braking: Built-in brake resistor for power above 0.4KW; external resistor for high inertia applications
Feedback Mode: 2500PPR incremental encoder
Digital Input: Multiple control signals including servo on, clear, direction control, and emergency stop
Digital Output: Status indicators for servo ready, alarm, position completed, and speed arrival
Speed Frequency Response: >400Hz
Speed Regulation Ratio: 1:5000
Driver Dimensions
IP20 Industrial Servo Drives 0.1KW - 3.8KW AC Servo Motor Drive For Precision Position Control
Wiring Diagram (Position Control)
IP20 Industrial Servo Drives 0.1KW - 3.8KW AC Servo Motor Drive For Precision Position Control
Certifications & Compliance
IP20 Industrial Servo Drives 0.1KW - 3.8KW AC Servo Motor Drive For Precision Position Control IP20 Industrial Servo Drives 0.1KW - 3.8KW AC Servo Motor Drive For Precision Position Control
Industry Applications
IP20 Industrial Servo Drives 0.1KW - 3.8KW AC Servo Motor Drive For Precision Position Control
Packaging & Delivery
IP20 Industrial Servo Drives 0.1KW - 3.8KW AC Servo Motor Drive For Precision Position Control
