22mm IP67 Momentary Metal Push Button Switch With Double Pole Double Throw
22mm IP67 Momentary Metal Push Button Switch With Double Pole Double Throw
22mm IP67 Momentary Metal Push Button Switch With Double Pole Double Throw
22mm IP67 Momentary Metal Push Button Switch With Double Pole Double Throw
22mm IP67 Momentary Metal Push Button Switch With Double Pole Double Throw
22mm IP67 Momentary Metal Push Button Switch With Double Pole Double Throw
22mm IP67 Momentary Metal Push Button Switch With Double Pole Double Throw
22mm IP67 Momentary Metal Push Button Switch With Double Pole Double Throw
22mm IP67 Momentary Metal Push Button Switch With Double Pole Double Throw
22mm IP67 Momentary Metal Push Button Switch With Double Pole Double Throw
22mm IP67 Momentary Metal Push Button Switch With Double Pole Double Throw
22mm IP67 Momentary Metal Push Button Switch With Double Pole Double Throw
Specifications
Payment Terms :
T/T
Max. Voltage :
250 V
Button pattern glow color :
Original color,red,Black,blue,yellow
Place of Origin :
Guangdong, China
Head Type :
Rotary Head, Dome Head, Flat Head
Material :
Stainless Steel
Button shape :
Flat round,High round,Spherical
Illuminated Type :
Ring Illuminated, Dot Illuminated
Switch material :
PA66
Delivery Time :
30
Mechanical Life :
2000000 Times
Brand Name :
Arcolps
MOQ :
1000
IP level :
IP65, Ip67
Product Name :
Metal button switch
Switch metal material :
Brass clad nickel,Stainless steel,Alumina
Model Number :
830122
Price :
$2.30-2.40 / piece
Switch body color :
Black,white,red,blue,yellow
LED :
Other
Whether The Smart :
No
Lifespan (hours): :
50000
Certification :
CE VDE CB
Max. Current :
2 A
Protection Level :
IP67
Structure :
Mechanical
Switch Combination :
1NO1NC, 2NO2NC
On button pattern luminous voltage: :
0V/12V/24V/110V/250V
Description
22mm IP67 Rated Stainless Steel Metal Button Switch With Double Pole Double Throw Configuration For Industrial Applications
Product Features
  • Arcolps 22mm Metal Button Switch IP67 Waterproof Momentary Latching Industrial Switch
  • High Durability Stainless Steel Push Button Switch 22mm for Machinery Control Panels
  • Industrial Grade IP65 Metal Push Button 22mm Momentary and Latching Options
  • 22mm Waterproof Metal Switch for Industrial Applications and Heavy Equipment
  • Momentary/Latching 22mm Button Switch Metal Shell for Marine and Outdoor Use
  • 22mm Panel Mount Metal Push Button Switch IP67 Rated for Harsh Environments
  • Reliable 22mm Industrial Control Switch Metal Construction Momentary Latching
  • Heavy Duty 22mm Metal Push Button Switch for Start Stop Control System
  • IP67 Waterproof 22mm Metal Button Switch Momentary/Latching Selector for Industry
  • Versatile 22mm Metal Button Switch with Momentary and Latching Industrial Design
Product Images
22mm IP67 Momentary Metal Push Button Switch With Double Pole Double Throw 22mm IP67 Momentary Metal Push Button Switch With Double Pole Double Throw 22mm IP67 Momentary Metal Push Button Switch With Double Pole Double Throw
Manufacturer Profile

Established in 2004, Shenzhen Arcolps Electronic Co., Ltd. is a leading manufacturer based in Bao'an, Shenzhen, with 20+ years of professional expertise in the R&D and production of high-performance switches and indicator lights.

Our products are widely applied in home appliances, automotive, medical, communications, power and marine industries, trusted by global customers for stable quality and reliable performance.

We feature 200,000 units daily production capacity, ready inventory for standard models, and only 30-day lead time for non-stock items. Backed by a professional R&D team, we provide efficient one-stop customization, completing design, tooling and mass production in just 60 days.

All products are certified with UL, CUL, CSA, ETL, CETL, ENEC, VDE and CQC, complying with strict international quality standards. We are committed to delivering premium, certified components and flexible solutions to empower your business with speed, reliability and innovation.

Packaging & Shipping
22mm IP67 Momentary Metal Push Button Switch With Double Pole Double Throw
