CE Rohs Control Room Video Walls
CE Rohs Control Room Video Walls
CE Rohs Control Room Video Walls
CE Rohs Control Room Video Walls
Specifications
Model Number :
SW-01
Certification :
CE,FCC, Rohs. CB
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
TT
Supply Ability :
5000pcs/month
Delivery Time :
7-25
Packaging Details :
Outer wooden box, middle carton, inner PE cotton
Brand Name :
Smart Display
Application :
indoor
view angle :
178°/178°(H/V)
Panel parameter :
RGB Vertical Stripe
bezel :
3.5mm
size :
55inch
Display colors :
8bit-16.7m
Customized service :
yes
Brand :
Smart Display
Description

49inch 55inch 65inch Wall Mount Indoor Hd Video Full Color lcd video lcd video wall display

Specification

Product size table
Panel size Bilateral seam Panel Length Panel Width Panel Thickness Panel Brand Model No.
46inch 1.7mm 1020.02mm 574.61mm 120.54mm Samsung LTI460HN15
46inch 3.5mm 1021.98mm 576.57mm 121.7mm Samsung LTI460HN11
46inch 5.5mm 1023.98mm 578.57mm 133mm Samsung LTI460HN09
49inch 1.8mm 1077.58mm 607.8mm 113.7mm LG LD490DUN-TJB2
49inch 3.5mm 1077.58mm 607.8mm 113.7mm LG LD490DUN-THC4
55inch 1.8mm 1213.5mm 684.3mm 110mm LG LD550DUN-THB8
55inch 3.5mm 1213.5mm 684.30mm 110mm Samsung LTI550HN11

CE Rohs Control Room Video Walls

CE Rohs Control Room Video Walls

Advantages of LCD Video Wall
Reliable quality and low maintenance: Less thermal diffusivity makes the components and parts more stable.
High Definition and clear image: High brightness and contrast make colors brilliant and bright, as well as stable and clear image.
Wide viewing angle: DID LCD panel makes the viewing angle up to 180°.
Low power consumption and low heat radiation
Long service life lowers the cost of usage and maintenance
Innovative and advanced: 42” to 60” Ultra thin bezel LCD video wall, the thinnest bezel up to 1.8mm
Ultathin and lightweighted: The ultra thin and lightweighted design makes it easy to transport and install.
Economical and practical: High performance and high quality make it cost less.
Key features
Support a variety of signal ports
Built-in splicing module , Support splice function
Support Creating one window PIP across the screen , roaming service , scaling , PIP
Support matrix joint control
Unique DNX motion supplement image processing technology
Dynamic image without motion trail
Splicing image processing RS-232 RJ45 loop-circuit input/output
Input by remote control with wire , mobile receiver head

Parameters
1, Original LG commercial grade lcd video wall display panel, 16:9 LG a-Si TFT-LCD
2, 700its brightness , MEGA DCR contrast
3, FHD physical resolution 1920x1080
4, Only 1.8mm Ultra narrow bezel , high quality , practical , good vision effect
5, Signal interface rich , RS232 , , DVI , VGA , Y Pb Pr , AV
6, FHD video wall unit , high brightness , high contrast , high gamut
7, Flexible structure design , easy installation , extensible , arbitrary combination
8, Stable performance , suitable working for a long time
