384V 100AH High Voltage LiFePO4 ESS Cabinet 38.4kWh Commercial Energy Storage System for Data Center
384V 100AH High Voltage LiFePO4 ESS Cabinet 38.4kWh Commercial Energy Storage System for Data Center
384V 100AH High Voltage LiFePO4 ESS Cabinet 38.4kWh Commercial Energy Storage System for Data Center
384V 100AH High Voltage LiFePO4 ESS Cabinet 38.4kWh Commercial Energy Storage System for Data Center
384V 100AH High Voltage LiFePO4 ESS Cabinet 38.4kWh Commercial Energy Storage System for Data Center
384V 100AH High Voltage LiFePO4 ESS Cabinet 38.4kWh Commercial Energy Storage System for Data Center
384V 100AH High Voltage LiFePO4 ESS Cabinet 38.4kWh Commercial Energy Storage System for Data Center
384V 100AH High Voltage LiFePO4 ESS Cabinet 38.4kWh Commercial Energy Storage System for Data Center
Specifications
Brand Name :
Silk
Model Number :
SLK-ESS-HV-38.4
Place of Origin :
Beijing, China
Certification :
CE, UN38.3, MSDS, IEC 62619, IEC 62040, RoHS
MOQ :
1pc
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
450Mwh/year
Delivery Time :
4-6 weeks for samples; 8-10 weeks for mass production
Packaging Details :
Wooden crate with custom foam protection, palletized freight
Voltage :
384V High Voltage DC
Capacity :
38.4kWh
Application :
Data Center, Commercial Solar, UPS Backup
Communication :
CAN + RS485 + Modbus RTU
Cycle Life :
6000+ cycles
Warranty :
10 Years
Description

384V 100AH High Voltage LiFePO4 ESS Cabinet

Engineered for demanding commercial environments, the 384V 100AH high voltage ESS cabinet delivers 38.4kWh of reliable energy storage in a compact floor-standing form factor. Designed specifically for data center UPS backup, commercial solar storage, and industrial peak shaving applications, this system provides mission-critical power with zero transition time. The high voltage architecture reduces system current, enabling thinner cabling, lower losses, and higher overall system efficiency.

Key Features

  • 38.4kWh Capacity: 384V 100AH configuration for commercial-scale energy storage
  • High Voltage Architecture: 384V DC bus reduces current by 8x compared to 48V systems
  • Integrated BMS: Multi-level protection with individual cell monitoring and thermal management
  • Data Center Ready: Compatible with major UPS systems for seamless backup power integration
  • CAN/RS485 Communication: Industrial-grade communication for BMS, EMS, and SCADA integration
  • IP54 Rated: Protected against dust and water spray for indoor installation

Technical Specifications

ParameterSpecification
Nominal Voltage384V DC
Nominal Capacity100AH / 38.4kWh
Battery TypeLiFePO4
Max Discharge Current200A
Peak Discharge (10s)400A
Cycle Life6000+ cycles @ 80% DOD
CommunicationCAN 2.0B / RS485 / Modbus RTU
IP RatingIP54
Dimensions (WxDxH)600 x 800 x 1800 mm
Weight380 kg
Operating TemperatureCharge: 0~50°C | Discharge: -20~55°C
CoolingForced Air (temperature-controlled fans)
Warranty10 Years
