768V 200AH Containerized LiFePO4 ESS 153.6kWh Industrial Energy Storage System for Grid Peak Shaving
768V 200AH Containerized LiFePO4 ESS 153.6kWh Industrial Energy Storage System for Grid Peak Shaving
768V 200AH Containerized LiFePO4 ESS 153.6kWh Industrial Energy Storage System for Grid Peak Shaving
768V 200AH Containerized LiFePO4 ESS 153.6kWh Industrial Energy Storage System for Grid Peak Shaving
768V 200AH Containerized LiFePO4 ESS 153.6kWh Industrial Energy Storage System for Grid Peak Shaving
768V 200AH Containerized LiFePO4 ESS 153.6kWh Industrial Energy Storage System for Grid Peak Shaving
768V 200AH Containerized LiFePO4 ESS 153.6kWh Industrial Energy Storage System for Grid Peak Shaving
768V 200AH Containerized LiFePO4 ESS 153.6kWh Industrial Energy Storage System for Grid Peak Shaving
Specifications
Brand Name :
Silk
Model Number :
SLK-ESS-CT-153.6
Place of Origin :
Beijing, China
Certification :
CE, UN38.3, MSDS, IEC 62619, IEC 62933, UL 9540, RoHS
MOQ :
1pc
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
450Mwh/year
Delivery Time :
8-10 weeks for samples; 12-16 weeks for mass production
Packaging Details :
Flat-rack or standard container shipping, factory pre-commissioned
Container :
10ft ISO Standard
Capacity :
153.6kWh
Scalability :
Up to 20 containers (3MWh+)
Cooling :
Integrated HVAC 5kW
Fire Safety :
Aerosol + Smoke + Heat Detection
Warranty :
10 Years
Description

768V 200AH Containerized Industrial ESS

The 768V 200AH containerized LiFePO4 energy storage system delivers 153.6kWh of industrial-grade power in a standard 10ft shipping container footprint. Factory pre-assembled and tested, this turnkey solution arrives on-site ready for connection to grid, solar, or generator inputs. Integrated HVAC thermal management, aerosol fire suppression, and intelligent EMS make it the reliable backbone for grid peak shaving, renewable energy firming, and critical industrial backup applications. Scale from kilowatts to megawatts by paralleling multiple containers.

Key Features

  • 153.6kWh per Container: 768V 200AH configuration in compact 10ft footprint
  • Turnkey Delivery: Factory pre-commissioned — crane into position, connect, and power on
  • Integrated HVAC: Active thermal management maintains optimal 25±5°C cell temperature
  • Fire Suppression: Aerosol-based automatic fire suppression system with smoke detection
  • Intelligent EMS: Built-in Energy Management System with remote cloud monitoring
  • MW-Scalable: Parallel up to 20 containers for 3MWh+ installations

Technical Specifications

ParameterSpecification
Nominal Voltage768V DC
Nominal Capacity200AH / 153.6kWh
Battery TypeLiFePO4
Max Power100kW Continuous
Cycle Life6000+ cycles @ 80% DOD
Container Size10ft Standard (ISO 668)
CoolingIntegrated HVAC (5kW cooling)
Fire ProtectionAerosol suppression + Smoke + Heat detection
CommunicationModbus TCP / IEC 61850 / CAN
Dimensions (LxWxH)2991 x 2438 x 2591 mm
Weight4500 kg
Operating Temperature-30~55°C (with HVAC)
Ingress ProtectionIP54 (Container)
Warranty10 Years
