48V 200AH Stackable LiFePO4 Battery 10.24kWh Modular Home Energy Storage System Expandable to 40kWh
48V 200AH Stackable LiFePO4 Battery 10.24kWh Modular Home Energy Storage System Expandable to 40kWh
48V 200AH Stackable LiFePO4 Battery 10.24kWh Modular Home Energy Storage System Expandable to 40kWh
48V 200AH Stackable LiFePO4 Battery 10.24kWh Modular Home Energy Storage System Expandable to 40kWh
48V 200AH Stackable LiFePO4 Battery 10.24kWh Modular Home Energy Storage System Expandable to 40kWh
48V 200AH Stackable LiFePO4 Battery 10.24kWh Modular Home Energy Storage System Expandable to 40kWh
48V 200AH Stackable LiFePO4 Battery 10.24kWh Modular Home Energy Storage System Expandable to 40kWh
48V 200AH Stackable LiFePO4 Battery 10.24kWh Modular Home Energy Storage System Expandable to 40kWh
Specifications
Brand Name :
Silk
Model Number :
SLK-ESS-ST-10.24
Place of Origin :
Beijing, China
Certification :
CE, UN38.3, MSDS, IEC 62619, RoHS
MOQ :
2pcs
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
450Mwh/year
Delivery Time :
2-4 weeks for samples; 4-6 weeks for mass production
Packaging Details :
Reinforced carton with custom-cut foam, palletized shipping
Installation :
Floor Stackable
Base Capacity :
10.24kWh per module
Max Expansion :
40.96kWh (4 modules)
Cycle Life :
6000+ cycles
Communication :
CAN + RS485 + WiFi
Warranty :
10 Years
Description

48V 200AH Stackable LiFePO4 Modular Home Energy Storage System

Scale your home energy storage effortlessly with our 48V 200AH stackable LiFePO4 battery system. Starting at 10.24kWh, each module connects seamlessly in series to deliver up to 40kWh of total capacity. The modular architecture eliminates complex wiring — simply stack, connect, and power your home. Each module features independent smart BMS with automatic cell balancing and inter-module communication for unified system management.

Key Features

  • Modular Stacking Design: Start at 10.24kWh, expand to 20.48kWh, 30.72kWh, or 40.96kWh by adding modules
  • Plug-and-Play Installation: Tool-free stacking connectors enable setup in under 30 minutes
  • Auto-Balancing BMS: Multi-module automatic balancing ensures uniform charge/discharge across all units
  • 6000+ Cycles: Premium LiFePO4 cells deliver over 15 years of daily cycling
  • LCD Touch Display: On-unit display shows SOC, voltage, current, temperature, and system status
  • Silent Operation: Passive cooling design with zero noise, ideal for indoor residential installation

Technical Specifications

ParameterSpecification
Nominal Voltage48V (per module)
Nominal Capacity (per module)200AH / 10.24kWh
Battery TypeLiFePO4
Max Stack4 modules (40.96kWh)
Max Discharge Current200A per module
Cycle Life6000+ cycles @ 80% DOD
CommunicationCAN / RS485 / WiFi (optional)
Dimensions (per module)500 x 200 x 600 mm
Weight (per module)85 kg
Operating TemperatureCharge: 0~55°C | Discharge: -20~60°C
Warranty10 Years
