TSXDSZ32R5 Schneider Electric 32-Output Relay Module
TSXDSZ32R5 Schneider Electric 32-Output Relay Module
TSXDSZ32R5 Schneider Electric 32-Output Relay Module
TSXDSZ32R5 Schneider Electric 32-Output Relay Module
TSXDSZ32R5 Schneider Electric 32-Output Relay Module
TSXDSZ32R5 Schneider Electric 32-Output Relay Module
Specifications
Brand Name :
Schneider
Model Number :
TSXDSZ32R5
Place of Origin :
China
MOQ :
1
Price :
$99
Payment Terms :
T/T
Supply Ability :
5000
Delivery Time :
In stock/1-3days
Packaging Details :
New sealed
Description

TSXDSZ32R5 Schneider Electric 32-Output Relay Module

The TSXDSZ32R5 is a 32-output relay discrete module from Schneider Electric's Modicon TSX Micro automation platform. This module is designed for industrial automation and control systems, offering 32 screw terminal block outputs with normally open (NO) contacts. It supports a wide range of output voltage limits, from 19 to 264 V AC and 10 to 34 V DC. The module has a thermal current rating of 2 A and a power consumption of up to 200 VA depending on the voltage and load type. It features a response time of less than 10 ms, ensuring rapid and reliable operation. The TSXDSZ32R5 also includes safety features such as an isolation voltage of 1500 V for 1 second and an insulation resistance of at least 10 megaohms. This module is RoHS compliant, ensuring environmental sustainability

Technical specifcations for TSXDSZ32R5
Parameter : Specification
Product Range : Modicon TSX Micro automation platform
Product Type : Relay discrete output module
Discrete Output Number : 32 screw terminal block
Contact Type : Normally Open (NO)
Output Voltage Limits : 19...264 V AC, 10...34 V DC
Thermal Current : 2 A
Power Consumption in VA
- 24 V AC-12 resistive : 50 VA
- 24 V AC-15 inductive : 24 VA
- 48 V AC-12 resistive : 100 VA
- 110...120 V AC-12 resistive : 200 VA
- 200...240 V AC-12 resistive : 200 VA
- 48 V AC-15 inductive : 50 VA
- 110...120 V AC-15 inductive : 50 VA
- 200...240 V AC-15 inductive : 50 VA
Power Consumption in W
- 24 V DC-12 resistive : 24 W
- 24 V DC-13 inductive : 24 W
Response Time < 10 ms
Current Consumption : 175 mA
Power Dissipation : 3.5 W
Isolation Voltage : 1500 V for 1 second
Insulation Resistance >= 10 megaohms
Compliance : RoHS compliant since 0919
Warranty Period : 18 months
More Products In Stock:
TSXDSZ32R5 140CHS11000 490NRP25400 140CPS52400
TSXP47455 140CPU11302 140AVI03000 140XBP00600
TSXP67455TSX6740 140DRA84000 140ACO13000 XBTGT2220

Our Services:

1,All our products are new and orginal, and of good quality

2,Our prices are very competitive.

3, We have a large quantity in stock, so we could help the customers to get the components which are dificult to get.

4,All inquiries will be valued and will reply in 24.

Packing & Delivery:

1,100% brand New and Original Factory Seal!

2,Warranty:1 year

3,Package: Original packing with cartons.

4,Delivery time: Shipped in 3-7 days after payment

5,All the goods will be tested before shipment
