ATV320U75N4C complex machine
ATV320U75N4C complex machine
Specifications
Brand Name :
Schneider
Model Number :
ATV320U75N4C
Place of Origin :
China
MOQ :
1
Price :
$99
Payment Terms :
T/T
Supply Ability :
5000
Delivery Time :
In stock/1-3days
Packaging Details :
New sealed
Description

ATV320U75N4C Schneider Relay Module

The ATV320U75N4C is a 7.5 kW variable speed drive designed for controlling three-phase asynchronous motors in complex machine applications. It operates within a supply voltage range of 380–500 V AC and features a rated output current of 17 A. This model supports advanced control profiles, including voltage/frequency ratio control and sensorless vector control, ensuring precise motor control and energy efficiency.
Technical specifcations for ATV320U75N4C
Power and Voltage:
Rated Output Power: 7.5 kW (heavy duty).
Supply Voltage Range: 380–500 V AC, three-phase.
Maximum Output Voltage: 500 V.
Current and Performance:
Nominal Output Current: 17 A.
Line Current: 26.5 A at 380 V (heavy duty), 18.7 A at 500 V (heavy duty).
Apparent Power: 16.2 kVA at 500 V (heavy duty).
Switching Frequency: 2–16 kHz adjustable, with a rated switching frequency of 4 kHz.
Control and Communication:
Communication Protocols: Modbus serial, CANopen. Optional modules available for EtherCAT, Profibus DP V1, PROFINET, Ethernet Powerlink, EtherNet/IP, DeviceNet.
Analogue Inputs: 3 channels (AI1: 0–10 V DC, AI2: ±10 V DC, AI3: 0–20 mA).
Digital Inputs: 7 channels (STO safe torque off, logic inputs).
Digital Outputs: 3 channels (open collector).
Relay Outputs: 2 channels (configurable relay logic).
Motor Control:
Control Profiles: Voltage/frequency ratio (2 points and 5 points), sensorless vector control, energy-saving mode.
Maximum Output Frequency: 0.99 Hz.
More Products In Stock:
ATV320U06N4B ATV320U02M2B ATV320U07M2B ATV320U07M2C
ATV320U07N4B ATV320U07N4C ATV320U11M2B ATV320U11M2C
ATV320U11N4B ATV320U11N4C ATV320U15M2B ATV320U15M2C

Our Services:

1,All our products are new and orginal, and of good quality

2,Our prices are very competitive.

3, We have a large quantity in stock, so we could help the customers to get the components which are dificult to get.

4,All inquiries will be valued and will reply in 24.

Packing & Delivery:

1,100% brand New and Original Factory Seal!

2,Warranty:1 year

3,Package: Original packing with cartons.

4,Delivery time: Shipped in 3-7 days after payment

5,All the goods will be tested before shipment
