ATV320U55N4C output power
ATV320U55N4C output power
Specifications
Brand Name :
Schneider
Model Number :
ATV320U55N4C
Place of Origin :
China
MOQ :
1
Price :
$99
Payment Terms :
T/T
Supply Ability :
5000
Delivery Time :
In stock/1-3days
Packaging Details :
New sealed
Description

ATV320U55N4C Schneider Relay Module

The ATV320U55N4C is a compact variable speed drive designed for controlling three-phase asynchronous motors in complex machine applications. It features a rated output power of 5.5 kW and operates within a supply voltage range of 380–500 V AC. This model supports advanced control profiles, including voltage/frequency ratio control and sensorless vector control, ensuring precise motor control and energy efficiency. The drive is equipped with integrated Class C2 EMC filtering and conforms to IP20 protection standards.
Technical specifcations for ATV320U55N4C
Power and Voltage:
Rated Output Power: 5.5 kW (heavy duty) .
Supply Voltage Range: 380–500 V AC, three-phase .
Maximum Output Voltage: 500 V .
Current and Performance:
Nominal Output Current: 14.3 A .
Line Current: 20.7 A at 380 V (heavy duty), 14.5 A at 500 V (heavy duty) .
Apparent Power: 12.6 kVA at 500 V (heavy duty) .
Switching Frequency: 2–16 kHz adjustable, with a rated switching frequency of 4 kHz .
Control and Communication:
Communication Protocols: Modbus serial, CANopen. Optional modules available for EtherCAT, Profibus DP V1, PROFINET, Ethernet Powerlink, EtherNet/IP, DeviceNet .
Analogue Inputs: 3 channels (AI1: 0–10 V DC, AI2: ±10 V DC, AI3: 0–20 mA) .
Digital Inputs: 7 channels (STO safe torque off, logic inputs) .
Digital Outputs: 3 channels (open collector) .
Relay Outputs: 2 channels (configurable relay logic) .
Motor Control:
Control Profiles: Voltage/frequency ratio (2 points and 5 points), sensorless vector control, energy-saving mode
More Products In Stock:
ATV320U06N4B ATV320U02M2B ATV320U07M2B ATV320U07M2C
ATV320U07N4B ATV320U07N4C ATV320U11M2B ATV320U11M2C
ATV320U11N4B ATV320U11N4C ATV320U15M2B ATV320U15M2C

Our Services:

1,All our products are new and orginal, and of good quality

2,Our prices are very competitive.

3, We have a large quantity in stock, so we could help the customers to get the components which are dificult to get.

4,All inquiries will be valued and will reply in 24.

Packing & Delivery:

1,100% brand New and Original Factory Seal!

2,Warranty:1 year

3,Package: Original packing with cartons.

4,Delivery time: Shipped in 3-7 days after payment

5,All the goods will be tested before shipment
