portable National Instruments GPIB-USB-HS+ GPIB Interface Module IEEE 488 Controller
portable National Instruments GPIB-USB-HS+ GPIB Interface Module IEEE 488 Controller
Specifications
Brand Name :
National Instruments
Model Number :
GPIB-USB-HS+
Place of Origin :
US
MOQ :
1
Price :
$99
Payment Terms :
T/T
Supply Ability :
5000
Delivery Time :
In stock/1-3days
Packaging Details :
New sealed
Dimensions :
3U, 6U, or 9U
Bandwidth :
100 MHz
Supported Interfaces :
USB, Ethernet, GPIB
Input Voltage Range :
±10V
Resolution :
16 bits
Input Impedance :
1 MΩ || 50 Ω
Weight :
1.5 kg
Maximum Sample Rate :
1 GS/s
Maximum Number Of Channels :
16
Form Factor :
CompactPCI
Description

GPIB-USB-HS+ GPIB Interface Module

The GPIB-USB-HS+ is an IEEE 488 controller and portable analyzer designed for computers with USB slots. It allows users to integrate instruments into systems using GPIB and troubleshoot GPIB hardware and software issues. This device offers the highest IEEE 488.2 performance, enabling control of up to 14 programmable GPIB instruments via a high-speed USB port. The improved design is compatible with almost all instruments, adds analyzer functionality, and reduces costs, speeding up application turnaround time. The device includes a license for the NI-488.2 driver software, which maximizes the reliability of GPIB connections with third-party instruments
Technical specifcations for GPIB-USB-HS+
Performance
GPIB Data Transfer Rates:
3-wire: Up to 1830 kbytes/s
HS488: Up to 7920 kbytes/s
Power Requirements
USB Bus-Powered Device:
+5 V (VBUS): 80 mA (Typical); 500 mA (Maximum)
Physical Characteristics
Dimensions: 8.0 cm × 6.1 cm × 2.0 cm (3.2 in. × 2.4 in. × 0.8 in.)
Weight: 153 g (5.4 oz), includes USB cable weight
Connectors:
GPIB: IEEE 488 24-pin connector
USB: USB Standard Type A plug
Jackscrew:
Thread: M3.5 × 0.6
Torque: 0.56 N·m (5.0 lb·in.), maximum
Environmental Conditions
Operating Ambient Temperature: 0°C to 55°C (Tested in accordance with IEC 60068-2-1 and IEC 60068-2-2.)
Operating Relative Humidity: 10% to 90%, noncondensing (Tested in accordance with IEC 60068-2-56.)
Storage Ambient Temperature: -20°C to 70°C (Tested in accordance with IEC 60068-2-1 and IEC 60068-2-2.)
Storage Relative Humidity: 5% to 95%, noncondensing (Tested in accordance with IEC 60068-2-56.)
Maximum Altitude: 2,000 m (at 25°C ambient temperature)
Pollution Degree: 2
Safety and Compliance
Safety Standards:
IEC 60950-1, EN 60950-1
UL 60950-1
CAN/CSA C22.2 No. 60950.1
Electromagnetic Compatibility:
EN 61326-1 (IEC 61326-1): Class A emissions; Basic immunity
EN 55011 (CISPR 11): Group 1, Class A emissions
EN 55022 (CISPR 22): Class A emissions
EN 55024 (CISPR 24): Immunity
AS/NZS CISPR 11: Group 1, Class A emissions
AS/NZS CISPR 22: Class A emissions
FCC 47 CFR Part 15B: Class A emissions
ICES-001: Class A emissions
CE Compliance:
2006/95/EC; Low-Voltage Directive (safety)
2014/30/EU; Electromagnetic Compatibility Directive (EMC)
Environmental Management
RoHS Compliance: The product complies with the Restriction of Hazardous Substances (RoHS) directive.
WEEE Compliance: At the end of the product life cycle, all products must be sent to a WEEE recycling center.
These specifications ensure that the GPIB-USB-HS+ is a reliable and high-performance device suitable for a wide range of applications involving GPIB and USB interfaces.
