Schneider TM258LF42DT logic controller, Modicon M258:

The Schneider TM258LF42DT is a compact and versatile logic controller from the Modicon M258 series, designed to meet the demands of industrial automation applications. It combines robust I/O capabilities, reliable power handling, and ample memory resources, making it an ideal choice for systems requiring compact and resilient control solutions.

Technical Specifications:

I/O Capabilities:

The controller features 42 discrete I/Os, including 10 fast inputs, 12 standard inputs, and 20 outputs (comprising 12 regular outputs and 4 fast outputs).

Input logic varies, with fast inputs and regular inputs being sink-type, while standard inputs are source-type.

Inputs accept a 24 V DC signal, with voltage states guaranteed above 15 V (active) or below 5 V (inactive).

Input impedance stands at 6 kOhm for both fast and regular inputs.

Memory Resources:

The controller is equipped with 128 MB of flash memory and 64 MB of internal RAM, providing ample space for complex logic and data-intensive applications.

Power Handling:

The TM258LF42DT operates on a 24 V DC power supply, with a voltage range of 20.4 to 28.8 V.

It has a rated current of 0.04 A for embedded expert modules power, 10 A for the I/O power segment, and 0.26 A for the main supply.

Peak current capabilities include up to 100 kA for the main supply (≤ 70 s), 25 kA for the I/O power segment (≤ 500 s), and 50 kA for embedded expert modules power (≤ 150 s).

Power consumption is rated at 13.03 W.

Connectivity Options:

The controller supports various communication interfaces, including CANopen and Ethernet, enabling seamless integration with other devices and systems.

It features embedded serial links and Ethernet ports (RJ45), as well as embedded Web and FTP servers for remote monitoring and management.

Physical Dimensions and Mounting:

The TM258LF42DT has a compact design, with dimensions of 175 mm (width) x 99 mm (height) x 85 mm (depth).

It weighs 0.55 kg and can be mounted on a symmetrical DIN rail for easy installation and integration into existing systems.

Environmental Standards and Certifications:

The controller complies with various environmental and operational standards, including UL 508, CSA C22.2 No 142, IEC 61131-2, and CSA C22.2 No 213.

It is also RoHS compliant, ensuring environmental sustainability and adherence to regulatory requirements.
