Aluminium Foil And Copper Foil Slitter Cylindrical Battery Electrode Slitting Machine
Product Overview

This semi-automatic slitting machine is designed for preparing electrodes of cylindrical and prismatic batteries in R&D laboratories and production lines. It efficiently processes aluminum and copper foil electrodes with precise dimensional accuracy and clean edges.

Key Features
  • Suitable for R&D laboratories and production line applications
  • Handles electrode widths up to 400mm with finished slitting width from 20mm to 400mm
  • Compatible with rechargeable lithium battery cathode and anode electrodes
  • Processes aluminum foil and copper foil base materials
  • Produces tidy sliced edges with high dimensional accuracy and no burrs
Technical Specifications
Model LITH-MQ350A
Source Voltage AC 110V-220V, Customized, 50HZ
Power 800W
Warranty One year limited warranty and lifetime support
Slitting Mode Single knife hobbing
Knife Type Upper and lower round knife
Slitting Width 20-500mm
Slitting Thickness 100-300um
Hob Diameter Φ80 mm
Slitting Speed 10m/min, Adjustable
Dimension (L*W*H) 610*610*1100mm
Weight 200kg
Additional Features
  • Interval cutting process: cut electrode into big pieces → feeding → roll and cut into small pieces → receive
  • Customizable cutting blade configuration according to customer requirements
  • Cutting width range: 20mm-500mm
  • Standard supply includes 5 sets of blades (quantity can be customized)
  • Knife material: Tungsten alloy for durability and precision
