0.4-0.8Mpa Lithium Battery Making Machine AC 220V Automatic Cell Sorting Machine
0.4-0.8Mpa Lithium Battery Making Machine AC 220V Automatic Cell Sorting Machine
0.4-0.8Mpa Lithium Battery Making Machine AC 220V Automatic Cell Sorting Machine
0.4-0.8Mpa Lithium Battery Making Machine AC 220V Automatic Cell Sorting Machine
Specifications
Description

Product characteristics:

Automatic online interface: It can be customized to connect the outlet of the automatic insulation paper pasting
machine to the machine hopper to realize automatic connection of the battery core and save labor costs.


Test effect: Repeated test, excellent effect.


Automatic collection of production quantity, showing current production efficiency.


Test data can be stored using a USB stick and transferred to a computer.


BT-1810 cell sorting machine
Power AC220V 50/60HZ 1.6KW
Air pressure 0.4-0.8Mpa,No water, no impurities
battery cell range 14430/14500/18500/18650/21700/26650/26700/32650/32700
Standard IR test HK3560
Optional tester HIOKI3561/HIOKI2562/HK3561
Efficiency About 5000pcs/h
Control device PLC Touch screen control
Run power Stepper motor
Voltage setting 0.00000V-6.0000V
Internal resistance 000.00mΩ-999.99mΩ
Channel 8-16 OK,1NG
Test data U disk storage,can be copied to the computer
Communication interface RS485
Test method 4-wire system
Test pin DZ100-214A30G
Dimensions L1100*W930*H1390MM/ L2260*W930*H1390MM
Weight About 110/160KG
