Automatic Grooving Machine Beading Machine For Batch Processing Of Battery
Automatic Grooving Machine Beading Machine For Batch Processing Of Battery
Specifications
Description

INTRODUCTION:

It is an auto grooving machine for cylindrical battery cases. It provides a continues workflow for case batch loading - neck grooving - case unloading without dedicated labor.

ADVANCED FEATURES:


· Efficient batch loading/unloading mechanism with case feeding conveyor

· Horizontally positioned grooving blade ensures the most stable and accurate grooving

· Micrometer assisted grooving depth & height adjustment

· Ability to compensate the axial deformation of a cylindrical casing

· User-friendly human-machine interface with PLC touch screen control

· Floor-Stand enclosure with transparent front & side openable windows allow clear process monitoring and adjustment





SPECIFICATIONS:


Working Voltage

110/220V AC, 50/60Hz

Max. Power Consumption

1KW

Air Pressure

0.5 MPa~0.8Mpa is required

Compatibility

Standard grooving capability for 18650 case
Note: CR123 / 18650 / 26650 / 32650 / AA is available upon request, please contact us for more details.

Control

User-friendly HMI with PLC touch screen control ensures easy program setup

Grooving Dimensions

Micrometer assisted grooving depth & height adjustment

· Depth: 1 - 2.0 mm

· Width: 1 - 1.5 mm

Grooving Accuracy

+/- 0.1 mm

Grooving Blade Life Span

>1 million times

Grooving Force

6kgf/cm^2

Compression Ratio

Percentage in height: 80%

Productivity

· Material feeding conveyor is able to load upto 22 pcs per batch

· 30 pieces per minute

Product Dimensions

W1080mm*D660mm*H1200mm

Net Weight

1000lbs

Warranty

· One year limited with lifetime support

· Rusting and damage due to improper storage condition or maintenance are not covered by warranty
