Single Family Wastewater Treatment Packaged Sewage Treatment Plant Small And Medium Sized
Single Family Wastewater Treatment Packaged Sewage Treatment Plant Small And Medium Sized
Specifications
Place of Origin :
Shandong,China
Brand Name :
Zhongqiao Enlightenment
Certification :
SGS,ISO
Model Number :
MBR-4
MOQ :
1Set
Price :
5200USD-15000USD
Packaging Details :
Container or customized
Delivery Time :
7-15 working days
Supply Ability :
100Set Per Month
Water treatment capacity (m³/d) :
100m³/d
Outline dimension :
9000×2250×2500mm
Weight of equipment :
6.15t
Running weight :
56.78t
Installed power :
11.73kW
Power consumption :
6.86kW
Cable specifications :
4mm²
Floor space :
53m²
Description

Single-Family Wastewater Treatment Facilities, Small and Medium-Sized Integrated Wastewater Treatment Equipment

ZhongqiaoBox integrated sewage treatment equipment covers a treatment capacity of 5–5,000 tons per day, and can be flexibly adapted to different scenarios through single unit, parallel connection of multiple units, or modular expansion.

1. Standard Treatment Capacity (Single Unit / Basic Module)
  • Small scale (5–50 tons/day): Rural sewage, small hospitals, homestays, emergency sites
  • Medium scale (50–500 tons/day): Residential quarters, towns, small and medium-sized factories, scenic spots
  • Large scale (500–5,000 tons/day): Industrial parks, centralized treatment, large emergency projects
2. Expansion Capacity (Modular Combination)
  • Adopts expandable container / skid mounted modules, with a single unit of 10–100 tons/day.
  • Multiple units in parallel can achieve flexible expansion to 20–500 tons/day.
  • Project examples:
    • Saudi Arabia project: 4 units in parallel = 1,200 tons/day
    • Tianjin / Xinjiang projects: up to 2,000 tons/day
3. Treatment Efficiency & Process
  • Main processes: AO, AO+MBR, stably removing COD, ammonia nitrogen, total nitrogen, total phosphorus.
  • Effluent standards: Level 1A / Level 1B, reclaimed water reuse, local discharge standards.
  • Strong shock resistance: adapts to water quality fluctuations, low sludge yield, stable operation.
4. Selection by Scenario
  • Rural areas / small hospitals: 5–50 tons/day
  • Residential quarters / towns: 50–200 tons/day
  • Industrial parks / large emergency: 500–2,000 tons/day
  • Ultra-large scale: 2,000–5,000 tons/day (multi-module combination)
Single Family Wastewater Treatment Packaged Sewage Treatment Plant Small And Medium Sized
Ten Reasons to Choose ZhongqiaoBox
  • Laser cutting and shearing machine blanking ensure high dimensional accuracy, less burr, easier assembly and welding.
  • In-house large bending machine for structural parts, assembly line production.
  • Pipe processing by pipe bender and threading machine, reducing welding, lower failure rate and better appearance.
  • Assembly line operation ensures short construction period and fast commissioning.
  • High-standard accessories and first-line brand electrical and mechanical equipment ensure stable operation.
  • Scientific water distribution design greatly improves tank utilization.
  • 55–60° sludge hopper design, no sludge accumulation.
  • Reasonable pipeline layout reduces head loss.
  • 12 years of production experience plus professional structural design team ensure firm and reliable structure under all working conditions.
  • Professional process engineers capable of independent design and optimization; we fully understand drawings and can integrate design concepts into production, giving the equipment “soul".

Single Family Wastewater Treatment Packaged Sewage Treatment Plant Small And Medium Sized

Market Position & Philosophy

At present, the integrated equipment market is mixed with poor reputation, and many units cannot operate normally. Numerous failure cases have caused a loss of confidence.

Although the process and equipment seem simple, due to the diversity of disciplines involved and industry characteristics, it is not easy to do simple things well, let alone to the extreme.

ZhongqiaoBox is committed to making simple equipment mechanized and standardized.We know that what is buried underground is not only a piece of equipment, but also humanity’s vision for a better life.

Single Family Wastewater Treatment Packaged Sewage Treatment Plant Small And Medium Sized

Equipment processing parameters

Processing parameter requirement

Parameters/Index

Inflow water quality

mg/L(ppm)

Outflow water requirement

mg/L(ppm)

COD

BOD

TSS

Ammonia nitrogen

TN

TP

PH

E.coli

Others

Water flow

m³/d

On/Underground

If underground,pls indicate the depth

If integrated with control room

Appearance requirement

Simple appearance, container appearance, Zhong qiao container appearance, please refer to our brochure for details

Voltage, HZ, Electric phase

Distance between regulating pool and equipment

Flange interface specifications

Special requirements
