Mobile Containerized Sewage Treatment System with Fast Installation and Easy Transport
Mobile Containerized Sewage Treatment System with Fast Installation and Easy Transport
Mobile Containerized Sewage Treatment System with Fast Installation and Easy Transport
Mobile Containerized Sewage Treatment System with Fast Installation and Easy Transport
Specifications
Brand Name :
Zhongqiao Enlightenment
Model Number :
MBR-2
Certification :
SGS
Place of Origin :
Shandong,China
MOQ :
1set
Price :
7600USD-15400USD
Payment Terms :
L/C,D/A,D/P,T/T,Western Union
Supply Ability :
120Set Per Month
Delivery Time :
15-30 working days
Packaging Details :
container or customized
Water treatment capacity :
50m³/d
Outline dimension :
6360×2040×2160mm
Weight of equipment :
3.55t
Running weight :
31.57t
Installed power :
7.87kW
Power consumption :
4.55kW
Cable specifications :
4mm²
Floor space :
39.97m²
Description
Product Introduction

The Mobile Containerized Sewage Treatment System is a compact, fully integrated, and movable wastewater treatment unit, designed for rapid deployment, simple transportation, and stable operation. It is widely used for domestic sewage, rural sewage, temporary construction sites, remote areas, emergency disaster relief, small industrial wastewater, and scenarios where traditional civil engineering sewage stations are difficult to construct.

Mobile Containerized Sewage Treatment System with Fast Installation and Easy Transport

Core Features
1. Mobile & Transportable
  • Encapsulated in standard 20ft / 40ft shipping containers
  • Can be easily transported by truck, train, or ship
  • Suitable for mobile, temporary, or remote projects
2. Fast Installation & Commissioning
  • Factory pre-assembled, piped, wired, and tested
  • On-site only needs leveling, water pipe connection, and power connection
  • Can be put into use within 3–7 days, greatly shortening the construction period
3. High Integration & Compact Structure
  • Integrates all processes in one container:
    • Pretreatment (grid, regulating tank)
    • Biochemical treatment (A/O, MBBR, MBR)
    • Sedimentation / filtration
    • Disinfection
    • Sludge treatment & control system
  • Small footprint, no need for large civil engineering pools
4. Stable & Efficient Treatment
  • Adopts mature and reliable processes:
    • MBBR: high load, strong impact resistance
    • A/O: efficient removal of COD, BOD, ammonia nitrogen
    • MBR: high-quality effluent, can be reused
  • Stable effluent quality, meeting national discharge standards
5. Fully Automatic Operation
  • PLC + touch screen control
  • Automatic aeration, dosing, backwashing, sludge discharge
  • Supports remote monitoring and alarm functions
  • Low labor cost, easy maintenance
6. Strong Environmental Adaptability
  • Corrosion-resistant container structure
  • Can be equipped with insulation, heating, and ventilation for low-temperature areas
  • Weatherproof, rainproof, snowproof, suitable for outdoor use

Mobile Containerized Sewage Treatment System with Fast Installation and Easy Transport

Mobile Containerized Sewage Treatment System with Fast Installation and Easy Transport

Main Applications
  • Rural domestic sewage
  • Tourist attractions, campsites, temporary events
  • Construction sites, mining areas, oilfield stations
  • Emergency disaster relief sewage treatment
  • Small factories, workshops, hospitals, schools
  • Islands, ships, remote areas without pipe network
Advantages Summary
  • Fast installation: greatly reduce construction time
  • Easy transport: movable and reusable
  • Small size: saves land and civil cost
  • Fully automatic: simple operation and maintenance
  • Stable effluent: reliable and compliant
  • Wide application: flexible for multiple scenarios

This system is an ideal choice for projects that require mobility, speed, simplicity, and low cost in sewage treatment.

Mobile Containerized Sewage Treatment System with Fast Installation and Easy Transport

model Water treatment capacity (m³/d) outline dimension weight of
equipment		 running
weight		 installed power Power
consumption		 running expense running expense Cable specifications floor space
L x W x H (mm) (t) (t) (kW) (kW) (Yuan/ton of water) (CNY/day) (mm²) (m²)
MBR-0.25 5 2720×1090×2160 1.18 7.58 5.365 3.245 4.08 20.41 2.5 19.38
MBR-0.5 10 3440×1090×2160 1.35 9.45 5.365 3.245 2.04 20.41 2.5 20.75
MBR-1 20 3890×1610×2160 1.83 15.36 7.165 4.145 1.14 22.87 4 24.26
MBR-1.25 30 5340×1610×2160 2.23 20.80 7.27 4.25 0.92 27.73 4 28.10
MBR-1.67 40 4910×2040×2160 2.45 24.09 7.87 4.55 0.87 34.78 4 31.02
MBR-2 50 6360×2040×2160 3.55 31.57 7.87 4.55 0.70 34.78 4 39.97
MBR-2.5 60 6360×2040×2660 4.05 38.56 7.87 4.55 0.67 40.07 4 39.97
MBR-3 70 7090×2040×2660 4.36 42.83 8.63 5.31 0.57 40.07 4 42.84
MBR-3.5 80 6890×2540×2660 4.91 51.46 10.23 6.11 0.58 46.12 4 48.63
MBR-4 100 8340×2540×2660 5.60 61.95 11.73 6.86 0.60 59.62 4 53.93
MBR-5 120 9060×2540×2860 6.21 72.03 13.73 7.86 0.76 91.58 6 58.51
MBR-6 150 11230×2540×2860 7.62 89.20 18.82 11.07 0.61 91.58 6 67.40
MBR-7 170 10510×2930×2860 8.04 96.11 18.82 11.07 0.54 91.58 6 70.29
MBR-8 200 12680×2930×2860 9.19 115.45 21.02 12.57 0.51 101.26 10 80.65
MBR-10 250 15580×2930×2860 11.16 141.72 26.07 15.27 0.51 127.18 10 101.15
MBR-12.5 300 9780×2930×2860
(in two groups)		 14.49 178.40 26.25 15.45 0.45 133.63 10 117.81
MBR-15 360 11230×2930×2860
(in two groups)		 16.02 204.23 34.65 20.35 0.48 171.94 16 131.31
MBR-17 400 12680×2930×2860
(in two groups)		 17.56 230.07 35.85 21.15 0.45 179.31 16 144.30
MBR-20 500 15580×2930×2860
(in two groups)		 21.45 282.56 39.45 22.95 0.36 179.31 16 171.30
