12-27kv-Length-584mm-3A-Various-Removable
12-27kv-Length-584mm-3A-Various-Removable
Specifications
Standard :
IEC 60282-2
MOQ :
30
Packaging Details :
Carton
Rated Current :
1, 2, 3, 5, 6, 8, 10, 12, 15, 20, 25, 30, 40, 50, 60, 65, 75, 80, 100, 120, 140, 200A
Melting Speed Ratio :
T type: 10~13 ; K type: 6~8
Environmental Conditions :
Ambient Temperature: -30℃ - +40℃, Altitude: 3000m, Frequency: 50Hz / 60Hz, Maximum Wind Speed: 35m/s
Price :
Negotiate
Delivery Time :
5-10 Days
Dimensions (mm) :
Array
Place of Origin :
China
Payment Terms :
L/C,D/A,D/P,T/T,Western Union
Description

JEC Type K and Type T Fuse Links

JEC Type K and Type T fuse links are engineered in complete accordance with ANSI/NEMA standards. Designed for precision, these fuse links ensure reliable system protection through rigorous manufacturing controls. They are capable of carrying 150% of their rated current without damage to the link or the cutout.

Key Advantages

  • Precision Engineering: Manufactured under continual quality control.
  • High Durability: Rated to carry 150% of current without degradation.
  • Compliance: Fully compliant with ANSI/NEMA and IEC 60282-2 standards.

Product Attributes

MOQ: 30 pieces
Packaging: Box, Carton, Pallet or Crate
Single Weight: 0.025 kg
Dimensions: 16 x 2 x 1.5 cm

Technical Specifications

ParameterDetails
Melting Speed RatioT type: 10~13 ; K type: 6~8
Rated Current1, 2, 3, 5, 6, 8, 10, 12, 15, 20, 25, 30, 40, 50, 60, 65, 75, 80, 100, 120, 140, 200A
StandardIEC 60282-2
Environmental ConditionsTemp: -30℃ to +40℃, Altitude: 3000m, Wind: 35m/s

Dimensional Data

Rated Current (A)A (mm)B (mm)C (mm)DF
1-2512.5±0.219.0±0.2530-60026.5
30-4012.5±0.219.0±0.2530-60038.0
50-10019.0±0.3N/A530-600510.0
120-20019.0±0.3N/A530-600712.0
