12-27kv-Length-584mm-5A-Various-Removable
12-27kv-Length-584mm-5A-Various-Removable
Specifications
Rated Current :
1, 2, 3, 5, 6, 8, 10, 12, 15, 20, 25, 30, 40, 50, 60, 65, 75, 80, 100, 120, 140, 200A
Price :
Negotiate
Payment Terms :
L/C,D/A,D/P,T/T,Western Union
MOQ :
30
Place of Origin :
China
Packaging Details :
Carton
Melting Speed Ratio :
T type: 10~13 ; K type: 6~8
Delivery Time :
5-10 Days
Environmental Conditions :
Ambient Temperature: -30℃ - +40℃; Altitude: 3000m; Frequency: 50Hz / 60Hz; Maximum Wind Speed: 35m/s
Standard :
IEC 60282-2
Dimensions (mm) :
Array
Description

JEC Type K and Type T Fuse Links

JEC Type K and Type T fuse links are precision-engineered to provide reliable system protection in full accordance with ANSI/NEMA standards. Manufactured under strict quality control, these fuse links are designed to carry 150% of their rated current without damage to the link or the cutout.

Key Advantages

  • ✅ Precision Manufacturing: Consistent performance under continual quality control.
  • ✅ High Durability: Designed to withstand 150% rated current.
  • ✅ User-Friendly Packaging: Supplied in perforated plastic bags for quick and easy access.
  • ✅ Compliance: Fully compliant with ANSI/NEMA and IEC 60282-2 standards.
Unit: Piece
MOQ: 30 Units
Package Size: 16 x 2 x 1.5 cm
Gross Weight: 0.025 kg

Technical Specifications

Melting Speed Ratio: T type: 10~13 ; K type: 6~8

Rated Current Range: 1, 2, 3, 5, 6, 8, 10, 12, 15, 20, 25, 30, 40, 50, 60, 65, 75, 80, 100, 120, 140, 200A

Rated Current (A) A B C D F
1-2512.5±0.219.0±0.212/24KV: 530-600, 36KV: 78726.5
30-4012.5±0.219.0±0.212/24KV: 530-600, 36KV: 78738.0
50-10019.0±0.3N/A12/24KV: 530-600, 36KV: 787510.0
120-20019.0±0.3N/A12/24KV: 530-600, 36KV: 787712.0
