Polymer Type Surge Arrester 36KV
Polymer Type Surge Arrester 36KV
Specifications
4/10μs High current impulse withstand :
100
MCOV (KV(rms)) :
29.0
30/60μs Switching current impulse (KV(crest)) :
92.4
8/20μs Lightning current impulse (KV(crest)) :
103
Code No. :
YH10W-36
Long impulse withstand current 2000 us :
250
Rated Voltage (KV(rms)) :
36
1/4μs Steep current impulse (KV(crest)) :
117
Description

Metal Oxide Arrester (MOA)

The Metal Oxide Arrester (MOA) represents the pinnacle of over-voltage protection technology. Utilizing high-performance Zinc oxide barriers, these units provide superior flow capacity compared to traditional silicon carbide arresters.

Core Advantages:

  • Advanced Protection: Effectively limits over-voltage energy to safeguard critical transmission and distribution infrastructure.
  • Non-linear Performance: Maintains microamp current flow under nominal voltage; triggers thousands of amps during lightning events.
  • High Reliability: Optimized core components for long-term operational stability.

Product Attributes

FOB UnitPiece
MOQ0
PackagingNot specified

Technical Specifications

Code No. Rated Voltage (KV) MCOV (KV) 8/20μs Lightning Impulse
YH5W-363629.0103
YH10W-363629.0103
