Porcelain Type Surge Arrester 18KV
Porcelain Type Surge Arrester 18KV
Specifications
Code No. :
Y5C-18
Place of Origin :
China
8/20μs Lightning impulse residual voltage ≤ KV(crest) :
54
4/10μs High current impulse withstand KV(crest) :
65
MCOV KV(rms) :
15.3
1.2/50μs Impulse discharge Voltage ≤ KV(rms) :
54
Power frequency discharge voltage ≥ KV(rms) :
33
Delivery Time :
5-10 Days
Long impulse withstand current2000us KV(crest) :
100
Payment Terms :
L/C,D/A,D/P,T/T,Western Union
Packaging Details :
Carton
Rated Voltage KV(rms) :
18
Price :
Negotiate
Description

Metal Oxide Arrester (MOA)

The Metal Oxide Arrester (MOA) represents the pinnacle of over-voltage protection technology. Utilizing advanced Zinc oxide barriers, this component offers superior flow capacity compared to traditional silicon carbide arresters. It ensures optimal safety for transmission and distribution equipment by efficiently releasing over-voltage energy during lightning strikes while maintaining minimal current flow under nominal voltage conditions.

Core Advantages

  • Advanced Zinc Oxide barrier technology
  • Superior over-voltage flow capacity
  • Low leakage current under nominal voltage
  • High-speed response to lightning surges

Technical Specifications

Code No. Rated Voltage (KV) MCOV (KV) Impulse Discharge (KV)
Y5C-18 18 15.3 54
Y10C-18 18 15.3 54
