Fully Automatic L-Type Sealing Shrink Wrapping Machine with Compact Footprint Easy Installation and High Durability Printing
Fully Automatic L-Type Sealing Shrink Wrapping Machine with Compact Footprint Easy Installation and High Durability Printing
Specifications
Price :
Negotiable
Delivery Time :
15-30 working days
Payment Terms :
T/T
Label Speed :
0-80pcs/min
Certification :
VERIFICATION OF CONFORMITY
Main Material :
stainless steel
Label Size :
40-240(L) 0.035-0.082(T)
Place of Origin :
CHINA
MOQ :
1 set
Voltage power :
AC220V/1.35KW | AC380V/12KW
Model Number :
ZRF-450L
Brand Name :
ZHIROBO
Overall Dimensions :
(L)650 (W)350 (H)550mm
Roll Outside Diameter :
Max 350mm
Description
Fully Automatic L-Type Sealing Shrink Wrapping Machine with Compact Footprint Easy Installation and High Durability Printing
Compact footprint and easy installation for space-constrained packaging environments
Product Overview
Fully Automatic L-Type Sealing & Shrink Packaging Machine ZRF-450L
Applications
Widely applicable for shrink packaging in industries including adhesive tapes, food, cosmetics, hardware, electronic components, gift boxes and other sectors.
Equipment Advantages
  • Maximum packaging speed reaches 15-20 packs per minute
  • Sealing & cutting station equipped with transparent glass protective cover for clear observation and safe operation
  • Special alloy sealing knife with non-stick film performance, firm sealing, no cracking, no coking, no smoke, and zero pollution
  • Imported relays convert electrical signals into optical signals for electrical isolation protection
  • Safety protection function prevents mis-cutting of packaging films and protects operator safety
  • Manual adjustment only required for package dimension changes; no mold replacement needed
  • Integrates film feeding, cutting, sealing and heat shrinking in one continuous line
  • Optimized film waste discharge function reduces film breakage faults
  • Jet-type hot air circulation system with freely adjustable temperature and electronic speed governor
Main Technical Parameters
Parameter Fully Automatic L-Type Sealing & Shrink Packaging Machine ZRF-450L Intelligent Visible Heat Shrink Tunnel DRS-4522
Voltage Power AC220V/1.35KW AC380V/12KW
Package Dimensions 500(L)*330(W)*150(H) 450(W)*200(H)
Sealing & Cutting Size Limit L+H < 480mm, W+H < 380mm
Sealing Bar Size 450mm*550mm
Wrap POF PVC, POF, PE
Speed/min 18/min 0-18/min
Machine Size 1700(L)*1050(W)*1450(H) 1800(L)*770(W)*1150(H)
Worktable Height 850±50mm 850±50mm
Shrink Chamber Inner Size 1500*450*250mm
Net Weight 300KG 150kg
Configuration Parameters
Component Fully Automatic L-Type Sealing & Shrink Packaging Machine ZRF-450L Intelligent Visible Heat Shrink Tunnel DRS-4525
PLC Controller SANJIEILI
HMI Touch Screen SANJIEILI
Motor MAILI MAILI
Relay OMRON
Sealing Knife SANJIEILI
Photoelectric Sensor SANJIEILI
Pneumatic Cylinder HENGYI
Air Filter Regulator AIRTAC
AC Contactor TIANGGAO
Circulation Fan SULIN
Switch TIANGGAO
Speed Governor DINGJIANPAI
Temperature Controller Shanghai Yatai
Equipment Layout
Fully Automatic L-Type Sealing Shrink Wrapping Machine with Compact Footprint Easy Installation and High Durability Printing

Fully Automatic L-Type Sealing Shrink Wrapping Machine with Compact Footprint Easy Installation and High Durability Printing
