Dual Station Sleeve Labeling Machine Auto Feed Automatic Shrink Sleeve Applicator Machine Twin Mode
Dual Station Sleeve Labeling Machine Auto Feed Automatic Shrink Sleeve Applicator Machine Twin Mode
Specifications
Model Number :
ZRB-1625X
Feature :
Sleeve labeling and Shrinking
Label Size :
Length: 30-250mm, Width: 30-150mm
Packaging Details :
Wooden Case
Payment Terms :
T/T
Delivery Time :
15-30 working days
Control Language :
English
Price :
Negotiable
Automatic Grade :
Automatic
MOQ :
1 set
Machine Size :
1300*700*1450mm
Place of Origin :
CHINA
Power Consumption :
1.5 kW
Certification :
VERIFICATION OF CONFORMITY
Brand Name :
ZHIROBO
Type :
Sleeve Labeling Machine
Description
Rotary Unscrambler Auto Feeding Sleeve Labeling Machine With Dual-Station Vacuum Labeling
Applications

This fully automatic rotary labeling & packaging system is designed specifically for electrical tape rolls. It integrates automatic feeding, sorting, sleeve labeling, film shrinking and paper card packaging in one continuous process.

Key Advantages
  • Stable high-speed operation up to 50 pieces per minute for efficient mass production.
  • User-friendly touch panel with programmable microcomputer control for flexible parameter setting.
  • Five sets of servo systems ensure high-precision positioning, film feeding, label suction, coding and film cutting with adjustable length and stable performance.
  • Dual-station rotary vacuum labeling system with in-position sensing supports non-stop label changing and uninterrupted production.
  • Fully automatic material handling, feeding and heat shrinking enable unmanned running.
  • Quick size changeover without extra tools, easy adjustment and high compatibility.
  • Built-in integrated vacuum generator for enhanced stability and automatic control.
  • Cantilever-type manual expansion shaft for simple and reliable film loading.
  • Easy operation, automatic fault alarm and intelligent one-key control function.
Technical Specifications
Parameter Value
Model ZRB‑1625X
Applicable packaging width 15–25 mm
Applicable roll diameter 50–130 mm (customizable for non-standard sizes)
Packaging speed Up to 50 pcs/min
Power supply AC380V‑4P, 8.5KW
Heat gun power 1.5KW * 2 units
Air pressure 0.5 MPa
Packaging film thickness 0.035–0.04 mm (shrinkage rate 50%)
Dimensions 2150*1955*2052 mm | 2065*578*1025 mm | 1335*1350*1342 mm
Net weight 2100 kg
Standard Configuration
Component Details
Model ZRB‑1625X
Touch screen control system
Servo systems & drivers Hokawa (turntable, film feeding, film cutting, label suction)
Gear reducers Smart & Mili
PLC controller & motion control system Hokawa
Circuit parts Zhengtai, Schneider, Mean Well, Yangming, Koizumi, Tatsuzumi
Pneumatic components Aiko, Yadeke, Painbo, Stars
Vacuum components Integrated vacuum generator (Aiko)
Bearings NSK
Guide rails Shangyin
Fiber amplifier & photoelectric sensor Bo Yi
Hot air gun Qinqi
Vacuum cylinder Dingcheng
Machine frame High-quality imported powder coating finish
Equipment Layout

Dual Station Sleeve Labeling Machine Auto Feed Automatic Shrink Sleeve Applicator Machine Twin Mode

Dual Station Sleeve Labeling Machine Auto Feed Automatic Shrink Sleeve Applicator Machine Twin Mode
