Designed for efficient and precise packaging of tape rolls and similar cylindrical products, this automatic packaging machine combines advanced servo control technology, intelligent PLC management, and high-precision positioning systems. It provides stable packaging quality, easy operation, and flexible production capability for both standalone use and fully automated production lines.

1. Advanced Pulse Cold Sealing Technology
Equipped with a pulse-type cold sealing cutter featuring a 500mm effective sealing width.
No preheating is required, allowing instant operation after startup.
Reduces energy consumption while achieving clean, smooth, and high-quality sealing results.
Ideal for applications requiring attractive packaging appearance and reliable sealing performance.

2. Flexible Product Size Adjustment
The width and diameter adjustment system is driven by a DC motor for accurate positioning.
Supports quick adaptation to different product dimensions, reducing setup time and improving production flexibility.
One-button specification change allows easy switching between packaging sizes.

3. Intelligent Film Feeding & Control System
PLC-based control system ensures stable and accurate machine operation.
Servo motor-driven film feeding provides precise packaging film length control.
Automatic waste film rewinding improves material utilization and simplifies operation.
Compatible with optional printed packaging films through adjustable servo-controlled film feeding parameters.

4. Stable Film Unwinding System
Magnetic powder clutch controls unwinding tension smoothly, ensuring stable film delivery without deviation.
Manual expanding shaft design enables fast and convenient film roll replacement.
Reduces downtime during material changeover.

5. High-Precision Detection System
Photoelectric sensors accurately detect product position during feeding.
Color mark detection system supports precise tracking of printed packaging films.
Ensures consistent packaging alignment and professional finished appearance.

6. Accurate Conveyor Control
The feeding conveyor adopts variable frequency drive control.
Provides smooth start/stop performance and precise product positioning.
Ensures reliable transfer throughout the packaging process.

7. Versatile Packaging Capability
Suitable for individual or multiple product packaging.
Handles products with widths ranging from 40mm to 350mm.
Different specifications can be changed quickly through the intelligent control system.
Maximum packaging speed reaches 15 pieces/minute.

8. Strong & Durable Machine Structure
Constructed with a robust steel frame for excellent stability and long-term durability.
Designed for continuous industrial operation with minimal maintenance requirements.

9. Optimized Mechanical Design
Separate main machine and conveyor structure simplifies transportation, installation, and maintenance.
Precision discharge positioning ensures products remain tightly wrapped without shifting.
Special separation mechanism prevents tape rolls from sticking together, allowing smooth and continuous feeding.

10. Easy Automation Integration
Designed for seamless connection with automatic or manual slitting machines.
Supports fully automated production lines for reduced labor requirements and improved manufacturing efficiency.

• High-quality cold sealing with low energy consumption
• Servo-controlled film feeding for precise packaging length
• Fast size adjustment for multiple product specifications
• Stable material feeding and accurate positioning
• Strong steel construction for industrial reliability
• Flexible integration with automated production systems
• Improved efficiency with reduced operator involvement

This Automatic Tape Roll Packaging Machine is an ideal packaging solution for tape manufacturers, converting factories, and industrial producers seeking reliable, efficient, and intelligent packaging automation.

This fully automatic color film sleeve wrapper is primarily designed for packaging whole drum or single printed color film applications, including masking tape, stationery tape, OPP box sealing tape, and similar products.
