Specifications

Model NO. :

A23

Connection Form :

Depend on Products

Driving Mode :

Depend on Products

Nominal Pressure :

Depend on Products

Channel :

Depend on Products

Structure :

Depend on Products

Type :

Depend on Products

Temperature :

-40 to + 180

Standard :

DN50-DN300: En1092 Pn10/16, ASME B16.5 Class150

Application :

Industrial Usage, Water Industrial Usage, Household Usage

Body :

ASTM A536 65-45-12, Wcb, CF8m

Disc :

ASTM A536 65-45-12 Nylon Coated, CF8, CF8m, 250

Seat :

EPDM, NBR, FPM

Stem :

Ss420, Ss431

Connection :

Wafer

Nominal :

DN50-DN2000

Operating Pressure :

16bar for DN50-DN300, 10bar for DN350- DN2000

Face to Face :

En558 Series 20, API 609 Table 1

Operation :

Hand Lever, Gear Box, Pneumatic Actuator, Electri

Transport Package :

Wooden Box

Specification :

Depend on products

Trademark :

Zegota

Origin :

China

Production Capacity :

10000 PCS

MOQ :

Description

A23 Wafer Concentric Butterfly Valves

The A23 Wafer Concentric Butterfly Valve is a high-performance, compact industrial fluid control solution engineered for demanding industrial applications. Featuring a precision-engineered concentric design where the valve stem aligns perfectly with the disc centerline, this valve ensures smooth operation and reliable sealing in low-to-medium pressure systems. Constructed with robust materials such as ductile iron, stainless steel, or specialty alloys, and paired with corrosion-resistant EPDM, NBR, or high-temperature Viton seals, it operates effectively across a temperature range of -20°C to 200°C, handling diverse media including water, steam, oils, and mild acidic/alkaline fluids.

Its space-saving wafer-style flange design simplifies installation and reduces pipeline complexity, making it ideal for space-constrained environments like municipal water supply, HVAC systems, food processing, and chemical plants. The lightweight structure, combined with low-torque operation, supports manual worm gear, pneumatic, or electric actuators for rapid response and precise flow control. Certified to ISO 5211 drive interfaces and API 609 fire-safe standards, the valve offers bidirectional sealing, a lifespan exceeding 100,000 cycles, and easy maintenance through replaceable seat seals-significantly reducing lifecycle costs. Typical applications include pump station shutoff, heat exchanger isolation, and industrial circulation control, positioning it as an optimal choice for efficiency-driven operations and cost-effective infrastructure.
