Fast Speed Portable WiFi Hotspot Router Moible 3/4G Wi-Fi Modem 2.4GHz
Fast Speed Portable WiFi Hotspot Router Moible 3/4G Wi-Fi Modem 2.4GHz
Fast Speed Portable WiFi Hotspot Router Moible 3/4G Wi-Fi Modem 2.4GHz
Fast Speed Portable WiFi Hotspot Router Moible 3/4G Wi-Fi Modem 2.4GHz
Specifications
Brand Name :
OEM
Model Number :
ZBT-EL976
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
10000 Units per month
Delivery Time :
15-30 Days(1000 units)
Product Name :
Fast Speed Portable WiFi Hotspot Router Mobile Hotspot 3/4G Wi-Fi Modem
Main chip :
Qualcomm MDM9207
Certification :
ROHS、CE
Operate System Supported :
Win XP/ 7 /8/10, MAC OS, Android （AP mode）
Dimension :
96 * 60 * 16 MM
Description

Fast Speed Portable WiFi Hotspot Router Mobile Hotspot 3/4G Wi-Fi Modem

Work for Europe and Africa:

4G: FDD-LTE B1/2/3/5/7/8/20

3g: UMTS: B1/2/5/8

2G: GSM: B2/3/5/8

Up to 150 Mbps DL and 50 Mbps UL

Product Specification

Item Description
Model EL976-L It is a LTE high-speed wireless router(MiFi)
Chipset Chipset Qualcomm MDM9207

Technical Standard

 FDD-LTE Up to 150 Mbps DL and 50 Mbps UL
UMTS Up to 42 Mbps DL and 5.76 Mbps UL(DC-HSPA+ mode)
GSM Up to 236Kbps (EDGE)
WLAN 802.11 b/g/n

Frequency Band

 FDD-LTE B1/2/3/5/7/8/20 (bands optional)
UMTS B1/2/5/8 (bands optional)
GSM B2/3/5/8
WLAN 2.4GHz

External Interface

 USB Type Micro-USB charge input and debug port
SIM/USIM Card Micro SIM card
Power button Long press 3 seconds to power ON or OFF
RESET button Reset to factory setting

Main Features

 Form Factor Mobile wireless router (MiFi,support AP& USB modem mode)
Visual Indicator(LED) LED dio display working status (signal/WiFi/data/battery cap)
Languages Supported English,Chinese or more language requested

Operate System Supported

 Win XP/ 7 /8/10, MAC OS, Android (AP mode)
Win XP/ 7 /8 (USB modem mode)

Battery

 Build-in NON removable
type Lithium ion polymer battery
capacity 2500mAh

WLAN

 Frequency 2400MHz～2483.5MHz
Channels 1 ~ 13

Manage mode

 Users 5
Web UI 192.168.43.1

Antenna

 Main antenna Build-in LTE/UMTS/EVDO/GSM main antenna
DIV antenna Build-in LTE/UMTS antenna
WLAN antenna Build-in WiFi antenna

Certification

 ROHS Supported
CE Supported
CCC Supported
Other Could be supported upon requested
Dimension L * W * H 96 * 60 * 16 MM

Standard Package Contents

 LTE MiFi 1
Quick Start Guide 1

Fast Speed Portable WiFi Hotspot Router Moible 3/4G Wi-Fi Modem 2.4GHz

Company Profile:

SHENZHEN ZHIBOTONG (ZBT) Electronics Co., LTD established in 2010, located at Shenzhen, China. ZBT is a manufacturer professional in R&D and producing network equipments, products are included POE switch, Access Point, openWRT wifi router, Vehicle router, outdoor CPE, 3G/4G wifi router, mobile router, Gpon products. ZBT also is a wifi coverage sloutions provider, provides the solution for hotel, school,hospital,enterprise,vehicle field etc.ZBT with 30 people R&D team and around 500 people in factory, 10,000 Square meters production scale, is very skilled at processing OEM/ODM design, also builds the long term cooperation with Mediatek, Broadcom,Qualcomm, capably offering good quality product and fast after-sale service.Till now, ZBT's products have exported to over 30 countries and regions.Adhere to the conception of 'High Quality, High Performance & High Satisfaction' , Each year ZBT would taken out more than 35% of the annual turnover as R&D funds to develop new products so as to satisfy clients' new coming requests.Customers' high satisfaction is ZTB's continuously pursue,high-quality&best service is ZBT's sincere promise to all clients. ZBT warmly welcome everybody joining in and build a win-win cooperation.

FAQ:

1. Do you provide customer LOGO?
Re: Yes, we accept to customize LOGO on firmware and hardware. But our MOQ is 1000 units.

2. Do you accept Sample Order?
Re: Yes, of course. Weclome to buy samples to make a test at the first time.

3. Do you provide firmware support?
Re: Sure thing, unlike other companies which are buying solutions from design company, we have our own firmware development team to support you.
