CPU

MT7628DAN MIPS24KEc Architecture CPU,Main frequency can up to 580MHZ

2.4G WIFI chips

MT7628DAN integrate 2.4G WIFI function
IEEE 802.11n/g/b,The fastest 300Mbps

Ram

DDR2 64MB,(do not support customized Ram capacity)

Flash

Nor Flash 8MB

Do not support NAND Flash

SIM card slot

NANO SIM card slot*1pc,support SIM/USIM

Type-C interface

Support PPS/PD3.0/PD2.0/QC4+/QC3.0/QC2.0/AFC/FCP/SCP/
PE2.0/PE1.1/SFCP fast charge output
support PD3.0/PD2.0/AFC/FCP/SCP/PE1.1 fast charge input

Type-A

SupportQC3.0/QC2.0/AFC/FCP/SCP/PE2.0/PE1.1/SFCP/Low voltage direct charge and fast charge output

Button

Reset button

Long press 10S to reset Mifi system.

Switch button

Short press 1S to display battery power,
No action for 40S, the device will be enter sleep mode automatic.
Long press 3S, ,Power on or Power off MIFI

Antennas

2 *FPC 2.4G antennas

2* FPC 4G mobile communication antennas, compatible with 3G/2G mobile data communication

WIFI LED

During the process of booting up the device, the LED light will be red.

After finishing boot up, and start up wifi function, the LED ligh will be
Green. If there is date communication, the LED light will be green and flashing.

After finishing boot up, If do not start up wifi function or wifi function

Failure, the LED light will be green.

LTE 4G LED

This LED light is controlled by the 4G module, and the specific definition is related to the 4G module. Generally, the 4G module is working normally,and dialing is not successful, the LED light will flash slowly.

If the dialing is successful, and there is data communication, the LED light will flash quickly.

When the 4G module fails, the LED light will not turn on

Fast charge LED

The LED light will always on when fast charge input or fast charge output

Battery level LED

There are 4 battery power LED lights, and each LED light indicates a power level (25%)
When there is a charging output, the battery level is automatically displayed
When there is a charging input, the battery power is automatically displayed, and the highest level LED of the current power is flashing to indicate that it is charging. When the battery is fully charged, the 4 LED lights are always on.
When the MiFi is turned on or off, and when the power bank function is in sleep mode, the battery level is not displayed. You can press the power button for 1 second to display the battery level, and it will automatically sleep if without any action in 40 seconds.
