ZBT-WE5928 Wholesale 300mbps Dual Band 8MB Flash 64MB RAM Wifi Wireless Router with SD Card Slot
ZBT-WE5928 Wholesale 300mbps Dual Band 8MB Flash 64MB RAM Wifi Wireless Router with SD Card Slot
ZBT-WE5928 Wholesale 300mbps Dual Band 8MB Flash 64MB RAM Wifi Wireless Router with SD Card Slot
ZBT-WE5928 Wholesale 300mbps Dual Band 8MB Flash 64MB RAM Wifi Wireless Router with SD Card Slot
Specifications
Brand Name :
OEM/ZBT
Model Number :
WE5928
Certification :
CCC,CE,ROHS, FCC
Place of Origin :
Shenzhen-China
MOQ :
1pcs
Price :
Negotination
Supply Ability :
10000pcs every week
Delivery Time :
Samples: 5 days; Bulk order: 25-30 days
Packaging Details :
1pcs device/1 packing box; 20pcs device with packing box/1 carton
Product Name :
ZBT-WE5928 Wholesale 300mbps Dual Band 8MB Flash 64MB RAM Wifi Wireless Router with SD Card Slot
Color: :
Black.White
Products Status :
New
RAM :
64MB RAM
LAN Ports :
3
WAN Ports :
1
Frequency :
300mbps
Wi-Fi Transmission :
802.11n
Function: :
FireWall, QoS, VPN
Wireless standard: :
IEEE802.11b/g/n
3G/4G :
4G Module
Wired Transfer Rate :
10/100Mbps, 10/100Mbps
Description

ZBT-WE5928 Wholesale 300mbps Dual Band 8MB Flash 64MB RAM Wifi Wireless Router with SD Card Slot

1. Simply Description:

The WE5928uses the latest MT7628N wireless solution, performs better and more function. Stable wireless performance, more functions , 2.4G 300Mbps, Also support 3G&4G function.One SD card slot. Beautiful share design.It is best choice to use home,office and other engineering project.

2. Product Features:

  • Support 802.11N/802.11G/802.11B network protocol, the max transmission rate could be 2.4G 300Mbps
  • Support 802.113/802.11U protocol, 3* 10/100M bps Auto MDI/MDIX
  • 1 Micro SD Card Slot
  • Support 3G/4G
  • With hardware watchdog, support redail up Internet after loosing Internet
  • Preload English openwrt firmware, support flash customer's firmware

Warm Reminder

Please check the modem bands!

The frequency bands of WE5926-E can be used in most of Europe, Asia and Africa countries.

Frequency Bands

FDD+TDD-LTE B1/3/5/7/8/20+B38/39/40/41
TDS B34/39
WCDMA B1/5/8
GSM 850/900/1800

Specification:

Hardware
Main Chipset MT7628NN
RAM DDR2 64MB (MAX DDR2 128MB)
SPI FLASH 8MB (MAX 16MB)
Protocol IEEE 802.11n.IEEE 802.11g.IEEE 802.11b.IEEE 802.3u
RT Power

802.11b 18dBm±2dBm;

802.11g 15dBm±2dBm;

802.11n 15dBm±2dBm;
Reception Sensitivity

802.11b: -83dBm@10% PER

802.11g: -74dBm@10% PER

802.11n: -68dBm@10% PER
Work Channel 2.4GHz choose :1-13
Wireless Rate Max 300Mbps
Work Frequency 2.4GHz
Antenna 2* 2.4G 5dBi antenna,2*4G 5dBi antenna, 2*4G FPC antenna
Interface

2*SIM card slot

1*Micro SD card slot

1*10/100M WAN port(Auto MDI/MDIX)
3*10/100M LAN port(Auto MDI/MDIX)
LED Power,PCIE mode ,2.4G,WAN,LAN1,LAN2,LAN3,
Button Reset/WPS
Max Power consumption < 12W
Others
Work Environments

Operating Temperature:0℃ ~ 40℃；
Storage Temperature:-40℃~ 70℃；

Operating Humidity:10%~90% non-condensing
Storage Humidity:10%~90% non-condensing
Adapter 9V 1A
Authentication CE, FCC, RoHs
Other accessories

Power adapter

FAQ

Can you printing Customer logo on products?

Yes, we can printing your logo on products.

Do you provide PCBA board order only?

Of course, as a OEM/ODM manufacturer, we can provide PCBA in a short time with good quality.

Can you desin products as per customer's requirements?

Yes, of course. We have our own R&D department, we have ability to design and produce at same time.

Do you....?

Maybe, why don't contact us now! Inquring us to see if we can, or if we do, to see if we can suprise you!
