300Mbps Router LTE Wifi Router 4G Lte Wireless Router
Simple Description
The WE826-T2 uses the latest wireless solution, performs better and more function. Stable wireless performance, more functions , 2.4G 300Mbps, Also support 3G, 4G (3G, 4G PCIE module is necessary), it could also dial-up via the USB port (should mount the 3G,4G network card). Provide 1 USB2.0 interface, 1 Micro slot.
Product Feature
Specification
| Hardware | |
| Main Chipset | MT7620A |
| RAM | DDR2 128MB (MAX DDR2 256MB) |
| SPI FLASH | 16MB (MAX 32MB) |
| Protocol | IEEE 802.11n, IEEE 802.11g, IEEE 802.11b, IEEE802.11ac, IEEE802.11a, IEEE 802.3, IEEE 802.3u |
| RT Power |
802.11b 18dBm±2dBm; 802.11g 15dBm±2dBm; 802.11n 15dBm±2dBm; |
| Reception Sensitivity |
802.11b: -83dBm@10% PER 802.11g: -74dBm@10% PER 802.11n: -68dBm@10% PER |
| Work Channel | 2.4GHz choose: 1-13 |
| Wireless Rate | Max. 300Mbps |
| Work Frequency | 2.4GHz |
| Antenna | 2* 5dBi antenna or 4*5dbi external antenna (With 3G/4G) |
| Interface |
1*PCI-E slot 1*SIM card slot 1*USB 2.0 port 1*Micro SD card slot 1*10/100/100M WAN port (Auto MDI/MDIX) |
| LED | Power, USB, 2.4G, WAN, LAN1, LAN2, LAN3, LAN4 |
| Button | Reset |
| Max Power consumption | < 12W |
| Others | |
| Work Environments |
Operating Temperature:0℃ ~ 40℃; Operating Humidity:10%~90% non-condensing |
| Adapter | 12V 1A |
| Authentication | CE, FCC, RoHs |
| Other accessories |
Power adapter, Ethernet cable
|
