Petrochemical Closed Type Industrial Water Cooling Systems With 10–90KW Heat Dissipation
Petrochemical Closed Type Industrial Water Cooling Systems With 10–90KW Heat Dissipation
Specifications
Brand Name :
YUDA
Certification :
CE ISO9001
Place of Origin :
China
MOQ :
1
Payment Terms :
T/T
Delivery Time :
30days
Packaging Details :
Wooden Case
Cooling Medium Flow Rate :
10 to 170 L per minute
Heat Dissipation Capacity :
10 – 90 kW
Operating Environment :
Industrial petroleum and petrochemical plants
Material :
metal,Iron case,Cold Rolled Steel,Aluminum
Noise Level :
≤ 65 dB
Dimension :
53*46*26mm,216*133*30mm,205mm*138mm*50mm,115 * 77 * 26mm (L*W*H)(card without metal box),94x71x26mm( W*L*H)
Fiber port :
Simplex SC,SM SC,duplex SC or FC,8 TX/RX SC Port
System Structure :
Fully sealed closed loop circulation
Filtration :
Integrated high-efficiency filter
Description
Petroleum and Petrochemical Grade Closed-Type Water Cooling System with 10–90 kW Heat Dissipation and 10–170 L/min Flow for Industrial Thermal Management
High Reliability Closed-Type Water Cooling Solution for Petroleum and Petrochemical Industrial Thermal Management. Designed specifically for petroleum and petrochemical industrial thermal management, this closed-type water cooling system provides stable heat dissipation from 10 to 90 kW with a cooling medium flow range of 10 to 170 L per minute, ensuring reliable and continuous cooling performance in high temperature, high load operating conditions.
Technical Specifications
Heat dissipation power range 10-90 kW
Cooling medium flow range 10-170 L/min
Temperature difference range ≥5℃ between inlet temperature of cooled device and inlet water temperature
Cooling medium Deionized water (external cooling: industrial circulating water)
System static pressure 0.15 MPa
Design pressure 1.0 MPa
Test pressure 1.0 MPa
PH external water coolant 6-9
System Components
  • Frame-cabinet design with strategically placed exhaust and drain valves for easy maintenance
  • Comprehensive system includes main circulating pump, electric three-way valve, filter, expansion tank, plate heat exchanger, and control system
  • Advanced temperature and pressure monitoring with both independent operation and remote control capabilities via terminal or serial port communication
  • Engineered for stability across various working conditions with optimized heat dissipation
  • Constructed with stainless steel and purple copper components for compatibility with deionized water cooling medium
Key Features
  • Designed for the petroleum and petrochemical industry, delivering 10-90 kW heat dissipation for stable thermal management under high load conditions
  • Fully closed loop system reduces contamination and fluid loss, ensuring safe and reliable operation for petroleum and petrochemical processes
  • Flexible flow range of 10-170 L/min with robust construction provides long term reliability for industrial petroleum and petrochemical applications
Global Market Applications
This Petroleum and Petrochemical Grade Closed-Type Water Cooling System is designed for reliable operation in industrial facilities worldwide. It meets the demanding needs of petroleum and petrochemical plants, supporting high thermal loads and long term equipment performance. Trusted globally, it ensures consistent and efficient cooling for diverse petroleum and petrochemical applications.
