472C Analogue Multimeter Multi Tester
472C Analogue Multimeter Multi Tester
472C Analogue Multimeter Multi Tester
472C Analogue Multimeter Multi Tester
472C Analogue Multimeter Multi Tester
472C Analogue Multimeter Multi Tester
472C Analogue Multimeter Multi Tester
472C Analogue Multimeter Multi Tester
472C Analogue Multimeter Multi Tester
472C Analogue Multimeter Multi Tester
472C Analogue Multimeter Multi Tester
472C Analogue Multimeter Multi Tester
472C Analogue Multimeter Multi Tester
472C Analogue Multimeter Multi Tester
Specifications
Measuring Current Range :
50uA~250mA
Measuring Voltage Range :
0.1~1000V
Model Number :
472
Brand Name :
Imhoo
Place of Origin :
Jiangsu, China
Dimensions :
1650x100x36mm
Measuring Capacitance Range :
100pF~2000uF
Measuring Resistance Range :
1~10KΩ
Operating Temperature :
10~40℃
color :
blue
MOQ :
200 pieces
Price :
$4.99-6.50 / piece
Description
472C Analogue Multimeter Multi Tester
472C Analogue Multimeter Multi Tester 472C Analogue Multimeter Multi Tester 472C Analogue Multimeter Multi Tester 472C Analogue Multimeter Multi Tester 472C Analogue Multimeter Multi Tester 472C Analogue Multimeter Multi Tester 472C Analogue Multimeter Multi Tester 472C Analogue Multimeter Multi Tester
Key Features
  • Transistor & LED Test Functionality
  • Continuity Test With Audible Buzzer
472C Analogue Multimeter Multi Tester
Technical Specifications
Measurement Function Ranges Accuracy
Capacitance Test 100pF~0.025uF/2.5uF/25uF .2000uF ±3.0F.S.
DC Voltage 100m/500m/2.5/10/50/250/1000v(20kΩ/V)
25kV(with Hvprobe)		 ±3.0F.S.
AC Voltage 10/50/250/1000v(9kΩ/V) ±4%f.s.
DC Current 50μ/2.5m/25m/250mA
2.5A,10A		 ±3%f.s
±5%f.s
Resistance 2/20k/200k/2M/20mΩ ±3% of arc.
NULL ±5V/±25V ±5%f.s.
dB -10-62dB -
Ll 150μ/1.5m/15m/150mA -
hFE 0-1000(w/TR connector) -
Battery test 1.5V -
Power Supply R6(1.5V)X2,6F22(9V)X1 -
Dimension 150×100×36mm -
Weight 280g -
Packaging Information
Parameter Specification
Packing Type Gift box (customizable)
Carton Size 54×32×30cm
Standard Packing per Carton 40pcs
Net Weight 14kg
Gross Weight 15kg
472C Analogue Multimeter Multi Tester
