High Lift Manual Pallet Truck 5000kg Rated Loading Capacity For Materials Handling Pallet Truck
High Lift Manual Pallet Truck 5000kg Rated Loading Capacity For Materials Handling Pallet Truck
High Lift Manual Pallet Truck 5000kg Rated Loading Capacity For Materials Handling Pallet Truck
High Lift Manual Pallet Truck 5000kg Rated Loading Capacity For Materials Handling Pallet Truck
High Lift Manual Pallet Truck 5000kg Rated Loading Capacity For Materials Handling Pallet Truck
High Lift Manual Pallet Truck 5000kg Rated Loading Capacity For Materials Handling Pallet Truck
Specifications
Brand Name :
YINGER HOIST
Model Number :
CBY
Certification :
CE GS ISO
Place of Origin :
China
MOQ :
1 set
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
1000 Set/Sets per Month
Delivery Time :
5-8work days
Packaging Details :
wooden cases,on pallets,and we can also make the packing according to buyers request.
Price :
Negotiable
Type :
5Ton Manual Pallet Truck
Oil Cylinder :
casting
Application :
materials handling
Rated Loading Capacity :
5000kg
Max. Lifting Height :
200mm
Min. Lifting Height :
85mm
Fork Length :
1150/1200mm
Fork Width :
550/685mm
Description

High Lift Manual Pallet Truck 5000kg Rated Loading Capacity For Materials Handling Pallet Truck

Capacity 2000kg/2500kg/3000kg/3800kg/5000kg can be choose

Fork size: 520/550/685 x 900/1100/1150/1220mm

Non-standard size can be choose, such as width 350-1100mm, length can be 650-3000mmm

Galvanzied or stainless type can be choose

High scissor palle truck can be choose.

Technical parameter of pallet truck
Model
CBY-AC 2.0
CBY-AC 2.5
CBY-AC 3.0
CBY-AC 3.5
CBY-AC 5.0
Capacity(kg)
2000
2500
3000
3500
5000
Min.fork height(mm)
75
85
Max.fork height(mm)
200
Fork length(mm)
1150/1200
1200
Fork overall width(mm)
550/685
685
Fork inner width(mm)
230/365
365
Front wheel size(mm)
74*70
80*70
Rear wheel size(mm)
180*50
Net weight(kg)
60/80
75/80
80-90
180

High Lift Manual Pallet Truck 5000kg Rated Loading Capacity For Materials Handling Pallet Truck
