YINGER HOIST 3000lbs Hitch Mounted Pickup Truck Crane Powder Coated Finish With Cable Winch pickup truck mounted crane
YINGER HOIST 3000lbs Hitch Mounted Pickup Truck Crane Powder Coated Finish With Cable Winch pickup truck mounted crane
YINGER HOIST 3000lbs Hitch Mounted Pickup Truck Crane Powder Coated Finish With Cable Winch pickup truck mounted crane
YINGER HOIST 3000lbs Hitch Mounted Pickup Truck Crane Powder Coated Finish With Cable Winch pickup truck mounted crane
YINGER HOIST 3000lbs Hitch Mounted Pickup Truck Crane Powder Coated Finish With Cable Winch pickup truck mounted crane
YINGER HOIST 3000lbs Hitch Mounted Pickup Truck Crane Powder Coated Finish With Cable Winch pickup truck mounted crane
YINGER HOIST 3000lbs Hitch Mounted Pickup Truck Crane Powder Coated Finish With Cable Winch pickup truck mounted crane
YINGER HOIST 3000lbs Hitch Mounted Pickup Truck Crane Powder Coated Finish With Cable Winch pickup truck mounted crane
Specifications
Brand Name :
YINGER HOIST
Model Number :
HP
Certification :
CE GS ROSH
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
1000 Set/Sets per Month
Delivery Time :
5-8work days
Packaging Details :
wooden cases,on pallets,and we can also make the packing according to buyers request.
Feature :
Truck Crane
Rated Loading Capacity :
500KG
Max. Lifting Height :
1940mm
Product name :
Vehicle mounted crane
Power :
12v 24v electric winch
Hook Capacity :
500kg
Steel tube :
Seamless pipe
Electric Winch :
3000LBS
Description

12/24V 500kg Small Pickup Electric Truck Crane With Cable Winch

YINGER HOIST 3000lbs Hitch Mounted Pickup Truck Crane Powder Coated Finish With Cable Winch pickup truck mounted crane

1. Compact design ,folds away when not in use.
2. Easily installed,on site or by a vehicle body builder.
3. Conforms to CE safety standard.
4. Unique technology of quick lifting.
5. Larger capacity than normal shop cranes at 3 position.
6. 360º swivel operating handle.
7. Forged heavy duty swivel hook.
8. 125% overload testing before delivery.

SPECIFICATIONS FOR 500kg Truck Crane
Single line Lifting Capacity(maximum)
500kg
Double-line Lifting Capacity(maximum)
800kg
Lifting Height Max.Std.(base to hook)
1940mm
Reach Max.(from center of rotation)
1490mm (see Figure 3)
Rotation (continuous) with Brake
360° Manual
Lifting Cable
4.8mm x 4.5m –1pc(for single-line lifting)
4.8mm x 5.5m—1pc(for double-line lifting)
Line speed with No Load
3.6m/min single line
Power Requirements
12V DC 125 amps
Switch Cable
4.2m
Mounting Base
250x250x18mms
Mounting Bolt Hole Pattern
170x170mms
Finish
Powder Coated
Packing Size
140x39x35cm
Weight
N.W.57kgs G.W.60kgs
YINGER HOIST 3000lbs Hitch Mounted Pickup Truck Crane Powder Coated Finish With Cable Winch pickup truck mounted crane
