DHK Type Small Overhead Lifting Hoist Overload Protection Good Lift Speed Stability 5 ton electric hoist
DHK Type Small Overhead Lifting Hoist Overload Protection Good Lift Speed Stability 5 ton electric hoist
DHK Type Small Overhead Lifting Hoist Overload Protection Good Lift Speed Stability 5 ton electric hoist
DHK Type Small Overhead Lifting Hoist Overload Protection Good Lift Speed Stability 5 ton electric hoist
DHK Type Small Overhead Lifting Hoist Overload Protection Good Lift Speed Stability 5 ton electric hoist
DHK Type Small Overhead Lifting Hoist Overload Protection Good Lift Speed Stability 5 ton electric hoist
DHK Type Small Overhead Lifting Hoist Overload Protection Good Lift Speed Stability 5 ton electric hoist
DHK Type Small Overhead Lifting Hoist Overload Protection Good Lift Speed Stability 5 ton electric hoist
Specifications
Brand Name :
YINGER HOIST
Model Number :
DHK
Certification :
CE GS ISO
Place of Origin :
China
MOQ :
1 unit
Payment Terms :
Western Union, T/T, L/C, D/A, D/P, MoneyGram
Supply Ability :
1000units per week
Delivery Time :
5-8work days
Packaging Details :
wooden cases,on pallets,and we can also make the packing according to buyers request.
Price :
Negotiable
Lifting Weight :
1-10Ton lifting hoist
Lifting Height :
3-20m
Sling Type :
Chain
Lift Speed :
73m/min
product name :
lifting chain hoist
Warranty :
1 Year
Overload protection :
included
Color :
Yellow or Customized
material :
printed
Push botton :
waterproof push botton
Description

DHK Type Small Lifting Hoist Electric Winch Electric Chain Hoist 1Ton Chain hoist

DHK Type Small Overhead Lifting Hoist Overload Protection Good Lift Speed Stability 5 ton electric hoist

Introduction of Lifting Hoist Electric Winch Electric Chain Hoist 1Ton Chain hoist

DHK is electric hoist, according to the German technological innovation of new products, Structure changed significantly, it has applied for natent. high lifting speed, running smoothly, small size, light weight, beautiful apperance. Applied to the factory, mine, pier, supermarket, warehouse. It could work with cargo trolley, improve working conditions, improve labor efficiency.

Features of Lifting Hoist Electric Winch Electric Chain Hoist 1Ton Chain hoist
Lifting speed stability

Light weight

High hardness and small wear

Model DHK1 DHK2 DHK3 DHK5 DHK10
Standard Capacity(ton) 1 2 3 5 10
Test Load(ton) 1.25 2.5 3.75 6.25 12.5
Voltage(V) 380 380 380 380 380
Motor Power (KW) 0.5 0.8 1.1 1.5 1.8
Lifting Speed (m/min) 3 2.5 2 2 1
Standard Lifting Height(m) 3 3 3 3 3
Min Space Between Hooks(mm) 300 380 470 600 730
Net Weight(kg) 42 50 55 62 100
Weight add of 1 meter(kg) 0.82 1.7 2.9 4.42 8.84

DHK Type Small Overhead Lifting Hoist Overload Protection Good Lift Speed Stability 5 ton electric hoist

DHK Type Small Overhead Lifting Hoist Overload Protection Good Lift Speed Stability 5 ton electric hoist
