HHBB 380V 3 Phase Electric Crane Hoist , Chain Pulley Hoist Aluminum Alloy Shell 2 ton electric chain hoist small hoist
HHBB 380V 3 Phase Electric Crane Hoist , Chain Pulley Hoist Aluminum Alloy Shell 2 ton electric chain hoist small hoist
HHBB 380V 3 Phase Electric Crane Hoist , Chain Pulley Hoist Aluminum Alloy Shell 2 ton electric chain hoist small hoist
HHBB 380V 3 Phase Electric Crane Hoist , Chain Pulley Hoist Aluminum Alloy Shell 2 ton electric chain hoist small hoist
HHBB 380V 3 Phase Electric Crane Hoist , Chain Pulley Hoist Aluminum Alloy Shell 2 ton electric chain hoist small hoist
HHBB 380V 3 Phase Electric Crane Hoist , Chain Pulley Hoist Aluminum Alloy Shell 2 ton electric chain hoist small hoist
Specifications
Brand Name :
YINGER HOIST
Model Number :
HHBB
Certification :
CE GS ISO
Place of Origin :
China
MOQ :
1 unit
Price :
Negotiable
Payment Terms :
Western Union, T/T, L/C, D/A, D/P, MoneyGram
Supply Ability :
1000units per week
Delivery Time :
5-8work days
Packaging Details :
wooden cases,on pallets,and we can also make the packing according to buyers request.
Lifting Weight :
0.5-32T
Lifting Height :
3-50m
Sling Type :
Chain
Lift Speed :
7.8m/min
product name :
HHBB hoist
Warranty :
1 Year
Overload protection :
included
Color :
Yellow or Customized
material :
printed
Push botton :
waterproof push botton
Description

Lifting Chain Hoist 1 Ton-20ton 380v 3phase Electric Chain Hoist

HHBB 380V 3 Phase Electric Crane Hoist , Chain Pulley Hoist Aluminum Alloy Shell 2 ton electric chain hoist small hoist

Shell: Aluminum alloy
Chain:TXK top quality loading chain
Bearing:Japan NSK Brand
Side Magnetic Brake:Top Quality
Gear:High Precision Level 7
Aluminum Parts(material):Casting Aluminum NO.ADC12Chain Wheel
Hoist Panels:Processed by grinding machine
Chain Wheel:QT600
Chain Container: Canvas / Sheet iron
Steel Parts:Q345
Gearbox:CNC Machining
Hooks: heat forging+heat treatment
Button Switch:4/6/8 buttons option ,made in Taiwan.Protection class: IP67
Warranty: 2 years for mechanical parts, 1 year for electric parts
Contactor: Eaton from USA / Schneider from Germany
Usage: Gantry Crane,Bridge Crane,Lifting Platform,Workshop,Construction Buliding,etc.
Power Specification:200~690V,50/60HZ,3 Phase
Customized logo acceptable

Model HHBB
0.5-01S 01-01S 1.5-01S 02-01S 02-02S 2.5-01S 03-01S 03-02S 03-03S 05-02S
nominal load (t) 0.5t 1t 1.5t 2t 2.5t 3t 5t
lifting speed (m/min) 7.2 6.6 8.8 6.6 3.3 5.4 5.4 4.4 2.2 2.7
moto power (Kw) 0.8 1.5 3.0 3.0 1.5 3.0 3.0 3.0 1.5 3.0
rotate speed (r/min) 1440 r/min
Motor insulation class F
working voltage 3-Phase 380V 50Hz
control voltage 24V / 36V / 48V
chain black number 1 1 1 1 2 1 1 2 3 2
chain size Φ6.3 Φ7.1 Φ10.0 Φ10.0 Φ7.1 Φ11.2 Φ11.2 10.0 Φ7.1 Φ11.2
net weight (kg) 47 61 108 115 73 115 122 131 85 151

HHBB 380V 3 Phase Electric Crane Hoist , Chain Pulley Hoist Aluminum Alloy Shell 2 ton electric chain hoist small hoist

HHBB 380V 3 Phase Electric Crane Hoist , Chain Pulley Hoist Aluminum Alloy Shell 2 ton electric chain hoist small hoist
