2400kg 173KWH Industrial And Commercial Energy Storage Lithium Battery IP54
2400kg 173KWH Industrial And Commercial Energy Storage Lithium Battery IP54
2400kg 173KWH Industrial And Commercial Energy Storage Lithium Battery IP54
2400kg 173KWH Industrial And Commercial Energy Storage Lithium Battery IP54
2400kg 173KWH Industrial And Commercial Energy Storage Lithium Battery IP54
2400kg 173KWH Industrial And Commercial Energy Storage Lithium Battery IP54
2400kg 173KWH Industrial And Commercial Energy Storage Lithium Battery IP54
2400kg 173KWH Industrial And Commercial Energy Storage Lithium Battery IP54
2400kg 173KWH Industrial And Commercial Energy Storage Lithium Battery IP54
2400kg 173KWH Industrial And Commercial Energy Storage Lithium Battery IP54
2400kg 173KWH Industrial And Commercial Energy Storage Lithium Battery IP54
2400kg 173KWH Industrial And Commercial Energy Storage Lithium Battery IP54
Specifications
Model Number :
YM010
Brand Name :
YIMA
Place of Origin :
Guangdong, China
Certification :
CE/RoHS/UN38.3/MSDS
Supply Ability :
100000 Piece/Pieces per Month
MOQ :
2 pieces
Price :
$6,996.00/pieces 2-9 pieces
Battery Type :
LiFePO4, LiFePO4 Battery Pack
Dimension (L*W*H) :
1300*1280*2400MM
Weight :
2400kg
Communication Port :
RS485, CAN
Protection Class :
IP54
Grid connection :
Hybrid grid
Cooling :
Air Cooling
Product name :
Solar Energy Storage Battery
Application :
Industrial and Commercial Energy Storage Battery
Cycle life :
6000 Times
OEM/ODM :
Aceeptable
Warranty :
3-5 Years
Communication :
CAN/RS485
Nominal Capacity :
173KWH
Battery cell :
BYD Cell
Port :
Shenzhen/Hongkong
Description

High Performance Lithium Battery Energy Storage System 173KWH for Industrial Commercial Energy Storage

Our Advantage:

12 years professional experience
5 years warranty
24 hours service time
100% grade A cells
Products Description
Model
YM010
Parameters
DC side voltage range
572V~738V
Output Voltage
380V@AC
Configuration
1P208S
Rated Power
100kW
Match PCS
100kW
Nominal Energy
173kWh
Dischargeable Energy
≥170kWh
Battery Cycle Efficiency
≥90%@AC
Dimension(L*W*H)
1300*1280*2400mm
Weight
2400kg
IP Level
IP55
Operating Temperature Range
-20-50℃
Operating Humidity Range
≤95%
Maximum working altitude
2000m
Battery temperature control method
air cooled
Fire Fighting System
Aerosol/perfluorohexanone
Communication Protocol
Modbus-RTU/TCP
Certified
GB/36276
2400kg 173KWH Industrial And Commercial Energy Storage Lithium Battery IP54
2400kg 173KWH Industrial And Commercial Energy Storage Lithium Battery IP54
2400kg 173KWH Industrial And Commercial Energy Storage Lithium Battery IP54

Company Profile
Shenzhen Yima Power Supply Co., Ltd. (hereinafter referred to as "Yima"was established in 2017. Yima is mainly committed to the research and development, producing and sales of lithium-ion 18650 21700 series cells and battery modules. Our products are widely used in four major sectors: Two-wheeler market (E-Bike, electric motorcycle/scooter, golf cart), Robot market (AGV, AI, early childhood education robot), Energy storage market (solar lights, industrial energy storage, household energy storage), Power tools market (garden tools, vacuum cleaners, sweepers).
Yima is High-tech enterprise, has passed the ISO9001 and ISO14001 quality and environmental management system, and all product have passed CE, UN38.3, MSDS, UL, ROSH and other certification.
Yima not only insist on principle of quality first, but also insist on the concept of technology first. And has cultivated a technical team from BAK, ATL, Sunwoda, central south University and other famous enterprise in the industry.
FAQ
Q1: Are you factory?
A1: Yes, our factory is in Shenzhen, China. Specializing in rechargeable batteries. Lithium ion batteries, lithium batteries and power batteries and chargers for more than 12 years.

Q2: Do your e-bike battery come with charger?
A2: All of our e-bike batteries come with charger.We have normal charger and fast charger.If you need fast charger please contact with us.

Q3: Do your electric bike batteries come with BMS?
A3: Yes, Our batteries all with SEIKO IC BMS, with stable performance.Which can protect the battery avoid short circuit,Overcharged,Overdischarge and Overcurrent.

Q4:How long is the battery expected to last?
A4: The battery should have around 800-1200 recharge cycles, about 2-3 years.Its capacity diminishes over time, when it goes down to 75%,you should replace it.The more you use the bike, the better the battery retains its capacity, since it keeps the Lithium moving.

Q5: How to maintain the battery?
A5: The battery should be stored in clean, dry, ventilated, dark environment when not using.Keep it after full charge,recharge it every 3 months or 6 months.

Q6: Can you provide OEM and ODM service?
A6: Yes, We are a professional Electric Bike Battery manufacture with factory, which produce all kind of high quality Ebike lithium batteries as customers' requirements and designs, welcome to place OEM and ODM orders and visit our factory.
