Portable Live Cable Fault Identifier and Direct Finder for High Voltage Underground Detection
Portable Live Cable Fault Identifier and Direct Finder for High Voltage Underground Detection
Specifications
Brand Name :
XZH TEST
Model Number :
XHSB505B
Certification :
ISO CE
Place of Origin :
Xi'an ShanXi China
MOQ :
1set
Payment Terms :
T/T
Supply Ability :
3000unit/year
Delivery Time :
5-8 work days
Packaging Details :
wooden packaging
Description

XHSB505B

A common and challenging problem encountered during on-site operations such as power cable laying, relocation, maintenance, and troubleshooting is identifying the correct cable. This is especially true when dealing with trenches containing numerous cables of the same specifications, leaving construction workers often at a loss. This device can quickly and accurately solve this problem.


Technical Parameters

Identification Method: Determined by the direction of the pointer's swing
Jaws Transmitter clamp: Φ125mm
Receiver clamp Φ200mm
Output Voltage: Range I (Direct Connection): 150V; Range II (Coupled Connection): 250V
Test Range Direct Connection: 0Ω～1kΩ
Coupled Connection 0Ω～50Ω
Pulse Current 0～10A
Pulse Period 2.75S/cycle
Power Supply Transmitter 12VDC lithium battery, handheld receiver AA battery


Working Principle

Detection of Cables Without Power:

The transmitter generates a special pulse signal, which is applied to the cable to be identified via a connecting wire. Based on the principle of electromagnetic induction, an induced signal will inevitably be generated along the cable, following the same pattern as the transmitted signal. At the testing site, a high-sensitivity receiving clamp and a handheld receiver are used to test all cables in the area. The cable to which the signal was applied (i.e., the cable without power) can be accurately located based on the indicator on the handheld receiver.


Detection of Cables with Power:

The transmitter generates a special pulse signal, which is applied to a point on the cable to be identified via a special transmitting clamp. Based on the principle of electromagnetic induction, an induced signal will inevitably be generated along the cable, following the same pattern as the transmitted signal. At the testing site, a high-sensitivity receiving clamp and a handheld receiver are used to test all cables in the area. The cable to which the signal was applied (i.e., the cable with power) can be accurately located based on the indicator on the handheld receiver.
