1920x1080 IPS LCD Module Full HD LVDS Screen 10.1 Inch For HMI And Embedded Devices
1920x1080 IPS LCD Module Full HD LVDS Screen 10.1 Inch For HMI And Embedded Devices
Specifications
Outline :
118.5×84.7×5.2 mm
Brand Name :
XXT
Signal Interface :
LVDS
Lumens Degrees :
1000cd/m²
Interface :
RGB, SPI, MIPI, LVDS, or Parallel
Display Mode :
Normally White, Transmissive
View Direction :
free/all
Viewing Area :
116.2mm×87.1mm
Place of Origin :
GuangDong, China
Color Gamut :
72 % of NTSC(Typ.)
Model Number :
YVO1010VQL-L1
Drive System :
a-Si TFT active matrix
Name :
IPS LCD Module
Controller Ic :
SSD1316
Storage Temperature :
-30℃~80℃
Lcm Dimension :
34.60(H) X 47.80(V) X 1.90(T)
Price :
$1.99-199.99 Piece
Response Time :
6ms
Display Color :
Monochrome Black and White
Payment Terms :
T/T
Supply Ability :
Up to 1,000 pcs/day
Delivery Time :
14-60 days
Operating_Temperature :
-20°C to 70°C
MOQ :
100 pcs
Description
10.1" IPS LCD Display Module 1920×1080 | Full HD LVDS Screen for HMI & Embedded Devices
Product Overview

The YZY 10.1 inch TFT LCD display module is engineered for embedded display systems, industrial equipment, medical devices, smart control terminals, and compact Full HD display applications. Featuring 1920*1080 Full HD resolution, IPS full viewing angle technology, and LVDS 40-pin interface, this module delivers exceptional image clarity, stable color performance, and reliable long-term operation.

With an ultra-slim 2.8 mm profile, anti-glare surface treatment, and high contrast ratio, this display module is perfectly suited for modern device integration requiring compact design and professional display performance.

Product Features
  • 10.1 inch IPS TFT LCD display module
  • 1920*1080 Full HD high resolution
  • LVDS 40-pin interface for embedded display systems
  • IPS full viewing angle technology
  • Normally black display mode for enhanced contrast
  • 16.7M color support for vivid image performance
  • HC anti-glare surface treatment reduces reflections
  • Slim and lightweight module structure
  • Stable LED backlight system
  • Support for customized brightness and touch solutions
Technical Specifications
Item Specification
Display Size 10.1 Inch
Resolution 1920 * 1080
Display Type IPS TFT-LCD
Display Mode Normally Black
Interface LVDS / 40 Pin
Color Depth 16.7M Colors
Viewing Angle 80/80/80/80
Brightness 280 cd/m²
Contrast Ratio 1000:1
Module Size 229.91 * 135.74 * 2.8 mm
Active Area 223.488 * 125.712 mm
Surface Treatment HC AG Anti-Glare
Operating Temperature 0℃ to +50℃
Storage Temperature -10℃ to +60℃
Backlight Structure 9*4 LED
Display Advantages

Full HD Resolution: 1920*1080 Full HD resolution provides sharp image rendering and detailed visual performance for industrial and multimedia applications.

IPS Full Viewing Angle: IPS technology ensures consistent color accuracy and image visibility from multiple viewing directions.

Slim Mechanical Structure: Ultra-thin 2.8 mm module thickness supports compact embedded device integration and modern product design requirements.

Anti-Glare Surface: HC AG surface treatment helps reduce reflections and improves readability under ambient lighting conditions.

Stable Industrial Performance: Designed for reliable operation in industrial control systems, portable equipment, and smart terminal devices.

Customization Services

Customization options are available according to project requirements:

  • Capacitive touch panel integration
  • High brightness enhancement
  • Interface customization
  • FPC structure modification
  • Cover glass customization
  • Optical bonding solutions
  • Mechanical structure adjustment
Typical Applications

Industrial Equipment: Suitable for industrial control panels, embedded monitoring systems, and automation equipment.

Medical Devices: Ideal for diagnostic equipment, portable medical instruments, and healthcare display terminals.

Smart Control Systems: Applicable to smart home control panels, wall-mounted terminals, and interactive control devices.

Portable Devices: Compatible with portable testing instruments, handheld terminals, and compact display equipment.

Multimedia & Embedded Displays: Supports Full HD display requirements for embedded video and graphical interface applications.

Mechanical Information
Item Dimension
Outline Size 229.91 * 135.74 mm
Thickness 2.8 mm
Active Area 223.488 * 125.712 mm
Quality Control

All display modules undergo strict quality inspection and functional testing before shipment to ensure stable performance and product reliability.

Supply & Service Advantages
  • Stable Inventory Support: Long-term supply capability for industrial and commercial display projects.
  • Professional Technical Support: Experienced engineering team supports product selection and customization requirements.
  • Flexible Order Quantity: Sample orders and volume production are both supported.
  • Global Shipping Support: International shipping solutions available for worldwide customers.
Frequently Asked Questions

Can this display support touch functionality?
Yes. Capacitive touch panel integration is available based on project requirements.

Is customization available?
Yes. Brightness, interface type, touch panel, cover glass, and FPC structure can be customized.

What is the typical lead time?
Standard models are usually shipped within 5–7 working days depending on stock availability.

What industries is this display suitable for?
Widely used in industrial control, medical equipment, embedded systems, smart devices, and portable display applications.

Do you provide samples?
Yes. Samples are available for evaluation and testing.

Ordering Information
Model Number Description
YVO1010VQL-L1 10.1 Inch IPS TFT LCD Module / 1920*1080 / LVDS 40 Pin
Manufacturer Information

XXT specializes in TFT LCD display modules and embedded display solutions for industrial, medical, smart device, and commercial applications. We provide stable product supply, customization support, and professional technical services for global customers.

Product Images
1920x1080 IPS LCD Module Full HD LVDS Screen 10.1 Inch For HMI And Embedded Devices 1920x1080 IPS LCD Module Full HD LVDS Screen 10.1 Inch For HMI And Embedded Devices 1920x1080 IPS LCD Module Full HD LVDS Screen 10.1 Inch For HMI And Embedded Devices 1920x1080 IPS LCD Module Full HD LVDS Screen 10.1 Inch For HMI And Embedded Devices
