Specifications
Model Number :
DN(B)-100,DN(B)-200,DN(B)-160,DN(B)-250
Application :
Sheet Metal Industries
MOQ :
1
Delivery Time :
30 working days
Keyword :
Resistance Spot Welding
After Warranty Service :
Video technical support, Online support and Spare parts
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Feature :
Stationary Welding Machine
Price :
USD35000-USD45000
Welding Material :
Metal Aluminum Stainless Steel
Certification :
CE, RoHs
Function :
Sheet Metal Spot Welding
Supply Ability :
30sets/month
Warranty :
12 months Guarantee
Brand Name :
XWH
Product name :
Aluminum Welded Sheet Metal Xy Moving Head Spot Welding Machine
Place of Origin :
China
Machine type :
Press Welding Machine
Packaging Details :
Wooden Case
After-sales Service Provided :
Free spare parts, Field installation, commissioning and training
Description

Steel Standing Industrial Pneumatic Automatic Welder Resistance Aluminum Welded Sheet Metal Xy Moving Head Spot Welding Machine

Product Introduction:

The automatic spot welding machine is based on a fixed spot welding machine, upgraded to dual electrode synchronous welding, and equipped with X/Y-axis moving fixtures and quick exchange racks to achieve efficient automated welding of elevator door panels. When operating, simply place the cut flat workpiece into the fixture, press the start button with both hands, and the equipment will automatically move the workpiece to the welding area. Then, perform programs such as pressurization, power on welding (thyristor controlled conduction angle), power-off pressure relief, etc., and finally move the workpiece to complete welding at other points before sending it to the fixture exchange rack. The design of pneumatic pressurization and vertical movement of the upper electrode ensures simple structure and reliable operation. The welding of 0.5-1.5mm thick plates is easy, and the overall size is 5250 × 3775 × 2067mm, which is safe and durable.


Features:

1. Controllable conduction angle of thyristor: The welding current can be continuously and finely adjusted to ensure optimal heat input for plates of different thicknesses (0.5-1.5mm).
2. Accurate segmentation of welding timing: The pressure, welding, maintenance, and rest periods are independently adjustable to meet the requirements of preventing splashing and overheating of thin plates.
3. Electrode vertical pressure stability: The upper electrode moves vertically up and down, with the pressure direction coinciding with the center of the solder joint, avoiding lateral slip and ensuring good consistency of the solder joint.
4. High X/Y-axis positioning accuracy: The mobile fixture adopts precision screw or synchronous belt transmission, with a repeated positioning error of ≤± 0.2mm, ensuring accurate welding point position.
5. The controller has constant current/constant voltage mode: real-time compensation for grid fluctuations and electrode wear, maintaining stable welding heat.


Detailed Images:

Cnc Automatic China Made Water-Cooled Resistance Pneumatic Heavy Duty Metal Sheet Multi-Head Multi Point Xy Spot Welding Machine

Double Electrode Head (up/down): A pair of copper alloy electrodes that directly contact the workpiece (welding 2 points at a time), apply current under pressure, concentrate heat on the contact surface of the plate to form a weld core, and complete spot welding.


Cnc Automatic China Made Water-Cooled Resistance Pneumatic Heavy Duty Metal Sheet Multi-Head Multi Point Xy Spot Welding Machine

X/Y Fixture Moving Mechanism: Driven by servo or stepper motor, the screw/synchronous belt accurately moves the workpiece in the horizontal plane, aligning the welding points of the door panel with the electrodes in sequence, achieving multi-point automatic welding.


Cnc Automatic China Made Water-Cooled Resistance Pneumatic Heavy Duty Metal Sheet Multi-Head Multi Point Xy Spot Welding Machine

Intermediate Frequency Control Box: Inverts AC power to DC power, achieving millisecond level high-precision welding, effectively reducing spatter, saving 30% energy, and significantly reducing transformer weight. It is particularly suitable for stable welding of materials such as aluminum and galvanized sheets.


Cnc Automatic China Made Water-Cooled Resistance Pneumatic Heavy Duty Metal Sheet Multi-Head Multi Point Xy Spot Welding Machine

Human Computer Interaction Interface: Touch screen or button panel, used to set welding parameters, call programs, display status and alarms, and achieve intuitive operation dialogue between people and devices.


Welding Test:


Cnc Automatic China Made Water-Cooled Resistance Pneumatic Heavy Duty Metal Sheet Multi-Head Multi Point Xy Spot Welding MachineCnc Automatic China Made Water-Cooled Resistance Pneumatic Heavy Duty Metal Sheet Multi-Head Multi Point Xy Spot Welding Machine

Cnc Automatic China Made Water-Cooled Resistance Pneumatic Heavy Duty Metal Sheet Multi-Head Multi Point Xy Spot Welding MachineCnc Automatic China Made Water-Cooled Resistance Pneumatic Heavy Duty Metal Sheet Multi-Head Multi Point Xy Spot Welding Machine

Welding Workpiece
Mainly used for welding various metal door panels, especially elevator door panels, by welding reinforced ribs on the back of the door panels to enhance structural strength. Its application scope is far beyond this, and it is also suitable for sheet metal processing in industries such as anti-theft doors, large cabinets, control cabinets, and household appliances. In terms of materials, it can easily handle spot welding connections of various common metal sheets such as low-carbon steel, stainless steel, coated steel plates, and aluminum alloys.


General Structures:

Cnc Automatic China Made Water-Cooled Resistance Pneumatic Heavy Duty Metal Sheet Multi-Head Multi Point Xy Spot Welding Machine

Cnc Automatic China Made Water-Cooled Resistance Pneumatic Heavy Duty Metal Sheet Multi-Head Multi Point Xy Spot Welding Machine

Technical Parameters:

Items Models DN(B)-100 DN(B)-160 DN(B)-200 DN(B)-250
Rated power (KVA) 100 160 200 250
Power input(V) 3φAC 380V 3φAC 380V 3φAC 380V 3φAC 380V
Max. short circuit current (KA) 30 35 40 45
Duty cycle(%) 50 50 50 50
Max. force(N) 6000 6000 10000 15000
Electrode length( MM) 450 450 450 500
Working stroke( MM) 80 80 80 80
Cooling consumption(L/min) 20 20 20 20
Max. welding capacity(MM) 3.0+3.0 4.0+4.0 5.0+5.0 6.0+6.0


Scene Images:

Cnc Automatic China Made Water-Cooled Resistance Pneumatic Heavy Duty Metal Sheet Multi-Head Multi Point Xy Spot Welding MachineCnc Automatic China Made Water-Cooled Resistance Pneumatic Heavy Duty Metal Sheet Multi-Head Multi Point Xy Spot Welding Machine
