Construction Used Spider Crane Telescoping Crawler Crane Used 150ton
Construction Used Spider Crane Telescoping Crawler Crane Used 150ton
Construction Used Spider Crane Telescoping Crawler Crane Used 150ton
Construction Used Spider Crane Telescoping Crawler Crane Used 150ton
Construction Used Spider Crane Telescoping Crawler Crane Used 150ton
Construction Used Spider Crane Telescoping Crawler Crane Used 150ton
Specifications
Brand Name :
Yugong
Model Number :
Yugong Spider Crane
Certification :
EPA、CE
Place of Origin :
Henan, China
MOQ :
1
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
1000
Delivery Time :
7-10days
Packaging Details :
frame
Weight (KG) :
3000
Marketing Type :
Ordinary Product
Core Components :
PLC, Engine, Bearing, Gearbox, Motor, Pressure vessel, Gear
Application :
Working in small spaces., Building Construction
Rated Loading Capacity :
3T 5T 8T
Applicable Industries Hotels, Garment Shops, Building Material Shops, Machinery Repair Shops, Manufa :
Yugong
Boom type :
Automatic 4 sections
Description
Construction Used Spider Crane Telescoping Crawler Crane Used 3T 5T 8T
Construction Used Spider Crane Telescoping Crawler Crane Used 150ton
Product Description

Spider crane hot sell in CHINA

Spider crane miniature design, small size, strong lifting capacity.Production range: 1.5 tons - more than 10 tons,The most
commonly used models: 3 tons -5 tons -8 tons. The model and configuration can be customized, the design is reasonable, the operation is simple, easy to learn and understand, and the work is stress-free.Use the wireless remote control or body switch to operate, and the operation is fast. Say goodbye to the era when you can only rely on human work in narrow spaces, which not only improves work efficiency but also ensures work safety.
Specification
Model
YG-30
YG-50
YG-80
Specification
3t
5t
8t
Maximum working radius
8.83mx0.15t
14mx0.5t
16.5m
Maximum above-ground head
9.9mx0.7t
16.8m
Winch device
Hook Speed
0-8m/min(4 rope)
12m/min(4 rope)
12m/min(4 rope)
Rope diameter
8mm-45m
11mm-80m
11mm-80m
Telescopic system
Boom Type
5-section boom, pentagonal structure
5-section boom, pentagonal structure
5-section boom, pentagonal structure
Boom Length/Time
3.1m-9.2m/20sec
12.3m/54sec
12.3m/54sec
Up and down
Boom Angle/Time
0°~78°/13sec
0°~78°/13sec
0°~78°/13sec
Slew system
Slew Angle/Speed
0-360°continuous/60sec
0-360°continuous/38sec
0-360°continuous/38sec
Traction system
Walking Way
Hydraulic motor drives
Hydraulic motor drives
Hydraulic motor drives
Walking Speed
0~2.5km/h
0~2.5km/h
0~2.5km/h
Grade Ability
(25°)36%
(25°)36%
(25°)36%
Operating characteristics
Manual operation, remote control
Manual operation, remote control
Manual operation, remote control
Transport parameters
L*W*H(mm)
2950*980*1560
5000*1500*1900
5000*1600*2180
Total weight(kg)
2700
6200
7200
The spider crane adopts rubber crawler hydraulic traveling device, and the hoisting, telescopic, undulating and rotating devices are all driven by hydraulic pressure. The whole machine adopts the design and optimization concept of three-dimensional modeling, finite element analysis and whole machine calculation. It has the advantages of good flexibility, convenient operation, compact structure, light and flexible operation, reliable use, and convenient maintenance. The machine is suitable for operations in narrow places where large cranes cannot be deployed.
Packing & Delivery
Applicable Industries
Hotels, Garment Shops, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Advertising Company, Other

Weight (KG)
3000

Video outgoing-inspection
Provided

Machinery Test Report
Provided

Marketing Type
Ordinary Product

Warranty of core components
3 years

Core Components
PLC, Engine, Bearing, Gearbox, Motor, Pressure vessel, Gear

Place of Origin
Henan, China

Warranty
2 years

Feature
Other

Condition
New

Application
Working in small spaces., Building Construction

Rated Loading Capacity
3T 5T 8T

Rated Lifting Moment
920MM

Max. Lifting Height
9.2mX0.7t

Brand Name
Yugong

Product name
mini Spider Crane

Brand Name:
Yugong Spider Crane

Key words:
mini spider crane

Product name:
mini crane 3 ton

Color:
Customized Color Acceptable

Package size per unit product:
5600.00cm * 900.00cm * 1000.00cm

Walking Way:
Hydraulic Motor

Safety system:
Safe load moment limiter

Boom type:
Automatic 4 sections

Crane screen:
Intelligent display screen

Packaging and delivery

Packaging Details
spider truck crane 5 ton spider crane loading container
