Specifications
Private Mold :
NO
Products Status :
Stock
Type :
Barcode Scanner
Scan Element Type :
CMOS
Colour Depth :
32 Bit
Interface Type :
usb
Max Paper Size :
A4 Size
Optical Resolution :
4mil
Scan Speed :
300M/S
Brand Name :
Eryin
Place of Origin :
Fujian, China
Warranty(Year) :
1-Year
After-sales Service :
Return and Replacement
color :
Black
Light Source :
Visual laser diode 630nm±10nm
scanning speed :
300 times / sec
Support interface :
USB,RS232,KB
Printing Contrast :
25% minimum reflective difference
Dimensions :
173(L)*64(W)*92(H)mm
Weight :
scanner135g Packing 145g
voltage :
Input Voltage DC5V Operating VoltageDC3.3V
Current :
Operating Current 70MA Standby Current 20MA
Operating Temperature :
-10℃~+50℃
Storage Temperature :
-40℃~+60℃
MOQ :
1 Piece
Price :
$8.50/pieces 200-499 pieces
Description
Product Paramenters
Performance Characteristics
CPU
32－BIT
Light Source
Visual laser diode 630nm±10nm
scanning speed
300 times / sec
Scanning Precision
4mil（1MIL=0.0254MM）
Scanning angle
corner±40° elevation±40° drift angle±45°
scanning mode
Manual or automatic induction (optional accessories)
Support interface
USB,RS232,KB
Printing Contrast
25% minimum reflective difference
Setting Mode
Manual (scan bar code in turn)
Program update
Computer Online Update
Decode Capability
One-dimensional
bar code
EAN13,EAN-8,UPC-A,Code39,Code93,Code128,codabar(nw-7),ISSN,ISBN,GS1
Databar,GS1-128 Composite Code,Code 11,Industrial25 ,MSI Plessey ，etc,ITF-6,ITF-14, China Post,interleaved 2 of 5...
Physical Characteristics
Dimensions
173(L)*64(W)*92(H)mm
Weight
scanner135g Packing 145g
voltage
Input Voltage DC5V Operating VoltageDC3.3V
Current
Operating Current 70MA Standby Current 20MA
Decode Ranges
Depth of Field and Resolution
4mil 30-65mm (EAN-13 4byte)
Depth of Field and Resolution
5mil 20-75mm (EAN-13 4byte)
Depth of Field and Resolution
13mil 20-250mm （EAN-13 13byte ）
Application scope
Express Logistics Supermarket chain Manufacture An institution etc
