300/500v Twin Electrical Cables with Earth Wire Flat Electrical Wires CU/PVC/PVC with bare earth wire 2x2.5+1.5mm2
300/500v Twin Electrical Cables with Earth Wire Flat Electrical Wires CU/PVC/PVC with bare earth wire 2x2.5+1.5mm2
300/500v Twin Electrical Cables with Earth Wire Flat Electrical Wires CU/PVC/PVC with bare earth wire 2x2.5+1.5mm2
300/500v Twin Electrical Cables with Earth Wire Flat Electrical Wires CU/PVC/PVC with bare earth wire 2x2.5+1.5mm2
300/500v Twin Electrical Cables with Earth Wire Flat Electrical Wires CU/PVC/PVC with bare earth wire 2x2.5+1.5mm2
300/500v Twin Electrical Cables with Earth Wire Flat Electrical Wires CU/PVC/PVC with bare earth wire 2x2.5+1.5mm2
Specifications
Brand Name :
Zhenglan cable
Model Number :
300/500v Twin Electrical Cables with Earth Wire Flat Electrical Wires CU/PVC/PVC with bare earth wire 2x2.5+1.5mm2
Certification :
3C，ISO 9001:2015，ISO 14001:2005
Place of Origin :
Henan, China
MOQ :
5000 meters
Price :
Negotiable
Payment Terms :
L/C,T/T,
Supply Ability :
70000m/day
Delivery Time :
15-30 days
Packaging Details :
100m/coil or as customized
Conductor Material :
99.99% oxygen-free Copper
Insulation :
PVC
Sheathed :
PVC
Type :
Insulated
Rate voltage :
300/500V
Description

Application:
Twin flat&Twin with earth ables 6192Y/6242Y is used fordomestic and light industrial wiring.it can be installed in dry or damp conditions clipped to surface,on trays or in free air where there is little risk of mechanical damage.Suitable for laying into trunking or conduit when mechanical protection isrequired.also suitable for embedded in plaster or laid in walls.


Construction :

1.Conductor: Bare copper wire(solid) class1 Bare copper multi wire(stranded) class2 2.Insulation:PVC Compound 4.Sheath: PVC Compound

3. Sheath Color:Grey , Black , White Techical Data : Standard:BS6004 Fixed installed: -30ºC up to +70ºC At short circuit of max.5s up to 160ºC Nominal Voltage: 300/500V Min inner bending radius:6D(D=Outdiameter) Behaviour in fire: Flame retardant cable acc.to IEC60332--1

No.of cores x Nominal section area Nominal Construction of conductor Nominal
Insulation
thickness		 Nominal
Sheath thickness		 Nominal
Overall diameter		 Nominal
Cable weight		 Max.Resistance of conductor
at 20ºC
No.X mm² No.X mm mm mm mm kg/km <=(Ω/km)
2x2.5+1.5 2x1.78+1.38 0,8 1,0 5.4x10.2 119 7,41

300/500v Twin Electrical Cables with Earth Wire Flat Electrical Wires CU/PVC/PVC with bare earth wire 2x2.5+1.5mm2

300/500v Twin Electrical Cables with Earth Wire Flat Electrical Wires CU/PVC/PVC with bare earth wire 2x2.5+1.5mm2

300/500v Twin Electrical Cables with Earth Wire Flat Electrical Wires CU/PVC/PVC with bare earth wire 2x2.5+1.5mm2
FAQ
Is your company a factory or a trade company?
Factory, more than 20 years in China
How long can I expect to get the sample?
After you pay the freight charge and send us confirmed files, the samples will be ready for delivery in 3-7 days. The samples will be sent to you via express and arrive in 3~7 days. You can use your own express account or prepay us if you do not have an account.
What are your payment terms?
We normally accept T/T 30% deposit, 70% balance before delivery as the main payment terms, and other payment can also be negotiated. Trade assurance on is also available.
What’s the delivery time?
Sample order needs 3~5 days. Formal order depends on the quantity. Usually it needs 7-30 days after get your payment.
What is your MOQ?
Generally it is 5000m.
