Drilling Rig Mud Pump Triplex Design For Efficient Hole Cleaning
Drilling Rig Mud Pump Triplex Design For Efficient Hole Cleaning
Specifications
Delivery Time :
30-45days
Rated strokes :
140r/min
Model Number :
F-1000
Discharge :
5″flange 5000psi
MOQ :
1 SET
Gear type :
A-type gear
Design :
Three Cylinder Single Acting
Payment Terms :
L/C, D/A, D/P, T/T, Western Union
Packaging Details :
woden carton
Type :
Triple cylinder, single action and piston type
Certification :
API 7K
Brand Name :
RIG
Application :
Efficient Hole Cleaning
Place of Origin :
China
Description

Common Faults of the Drilling Pump

1. Pump pressure drop and insufficient displacement: Mostly caused by damaged and washout pistons, failed sealing of the suction and discharge valves, and liner wear.

2. Severe pressure fluctuation and heavy pump vibration: Caused by incorrect pre-charge pressure in the air chamber (pulsation dampener), or cavitation due to poor suction.

3. Valve knocking and abnormal noise: Caused by worn or damaged valve flaps (valve plates) and valve seats.

4. Overheating and abnormal noise in the power end: Caused by insufficient lubrication and worn bearings and gears.

During drilling operations, the operators must continuously monitor the pump pressure and the running sound of the pump, and regularly inspect and replace the wear parts. Once the drilling pump fails and circulation stops, drilling must be halted in accordance with operating procedures and circulation must be restored within a short time — a long pump shutdown can easily trigger downhole accidents.

Drilling Rig Mud Pump Triplex Design For Efficient Hole Cleaning

Model F800 F1000 F1300
Type Triple cylinder, single action and piston type Triple cylinder, single action and piston type Triple cylinder, single action and piston type
Max. cylinder liner Dia stroke 170×229mm(6-3/4″×9″) 170×254mm(6-3/4″×10″ 180×305mm(7″×12″)
Rated strokes 150r/min 140r/min 120r/min
Rated power 596kW(800hp) 746kW(1000hp) 969kW(1300hp)
Gear type A-type gear A-type gear A-type gear
Gear speed ratio 4.185:1 4.207:1 4.206:1
Lubrication Forced and splashed lubrication Forced and splashed lubrication Forced and splashed lubrication
Suction 10″flange (about 254mm) 12″flange (about 305mm) 12″flange (about 305mm)
Discharge 5″flange 5000psi 5″flange 5000psi 5″flange 5000psi
Diameter. of the small gear shaft 177.8mm(7″) 196.9mm(7-3/4″) 215.9mm(8-1/2″)
Pin Key 44.45×44.45mm
(1-3/4″×1-3/4″)		 50.8×50.8mm
(2″×2″)		 50.8×50.8mm
(2″×2″)
Valve chamber Top body of the valveAPI#6 Top body of the valveAPI#6 Top body of the valveAPI#7
Approximate weight 14000 kg
30837lb		 18790 kg
41420 lb		 24572 kg
54170 lb
