Specifications
Standard :
API Spec 8C
Supply Ability :
10 set/month
Material :
High Strength Alloy Steel
Safety Device :
Reliable Safety Device
Price :
USD10000-50000/set
Place of Origin :
China
Sheave Groove :
Induction Hardened
Brand Name :
Xi'an Rig
Payment Terms :
L/C,D/A,D/P,T/T,Western Union
MOQ :
1 SET
Feature :
Wear Resistant
Certification :
API-8C
Model Number :
YG225
Delivery Time :
5-7days
Packaging Details :
woden carton
Type :
Traveling Block And Hook
Description

Traveling Block and Hook

Our traveling block and hook assembly, compliant with API Spec 8C, features a reliable safety device, high-strength alloy steel construction, and induction-hardened sheave grooves for enhanced durability and wear resistance.

The traveling block and hook assembly is a critical component in drilling operations, designed to provide reliable performance and enhanced safety. This assembly integrates the traveling block and hook into a compact unit, reducing overall length and better accommodating top-drive drilling systems. Key features include a dependable safety device at the main hook, high-strength alloy steel construction, and non-destructive testing for key components. The sheave grooves are induction-hardened to improve surface hardness and wear resistance, significantly extending the product’s service life.

Specifications Table

ModelYG135YG170YG225
Max. Hook Load1350 kN (150 US ton)1800 kN (200 US ton)2250 kN (250 US ton)
Sheave O.D760 mm (30 in)915 mm (36 in)915 mm (36 in)
Sheave Quantity455
Wire Rope Dia.26 mm (1 in)28.6 mm (1-1/8 in)32 mm (1-1/4 in)
Main Hook Opening Size150 mm (6 in)180 mm (7 in)190 mm (7-1/2 in)
Main Hook Dia.140 mm (5-1/2 in)150 mm (6 in)140 mm (5-1/2 in)
Assistant Hook Dia.90 mm (3-1/2 in)120 mm (4-3/4 in)120 mm (4-3/4 in)
Size (L x W x H)2943 x 840 x 653 mm (116 x 33 x 26 in)3307 x 960 x 630 mm (130 x 38 x 25 in)3450 x 970 x 840 mm (136 x 38 x 33 in)
Weight3200 kg (7050 lb)4585 kg (10100 lb)4732 kg (10432 lb)
API 8C Traveling Block And Hook Wear Resistance Travelling Block Hook High Strength
Traveling Block and Hook in Stock
