Specifications
Model Number :
4116
Place of Origin :
Shaanxi, China
Brand Name :
PR electronics
MOQ :
5 pieces
Payment Terms :
L/C,D/A,D/P,T/T,Western Union
Series :
4000
Features :
A signal transmitter
Mounting Type :
Open mounting
Description :
Signal transmission, Multi-purpose signal transmitter
Manufacturing Date Code :
2025
Type :
Signal transmission
Usage :
Signal conversion, signal protection
Theory :
Multi-purpose signal transmitter
Output :
0-20mA or 4-20mA or 0-10v
Connector :
terminal
Power supply :
Ac or DC
Description
PR Electronics 4116 Multi-purpose signal Transmitter Analog Output 2 Relay Output Temperature Pressure Flow Liquid Level
Products Description
Model number
4116
place of origin.
Denmark
brand
PR electronics
Feature
A signal transmitter
Input:

mA, measuring range/minimum range
0... 23 mA / 16 mA
V, measuring range/minimum range
0... 12 VDC / 0.8 V
RTD, measuring range/minimum range
- 200... +850°C / -
Lin.R, measuring range/minimum range
0... 10000 Ω / -
potentiometer
10 W... 100 kW
Sensor connections, cables
RTD 2-wire, 3-wire, 4-wire
TC type
BEJKLNRSTUW3W5Lr
Cold-end compensation
Internal/external
Reference voltage / 2-wire power supply
- / 16 VDC
Output:

mA, signal range/minimum range
0... 23 mA / 16 mA
Load (@ current output)
≤ 800 W
V, signal range/minimum range
0... 10 VDC / 0.8 VDC
Load (@ voltage output)

relay
2 x SPST, AC: 500 VA
Technical specifications:
Ambient temperature
- 20... +60°C
Supply voltage, general purpose, AC/DC
21.6... 253 V/19.2... 300 V
Maximum power consumption
2.5W
Isolation voltage, test/work
2.3 kVAC / 250 VAC
Response time
< 400 ms
Signal dynamic range, input/output
24 bit / 16 bit
precision
< Measuring range of ±0.1%
Temperature coefficient
< ±0.01% of the range / °C
NAMUR
NE21, NE43
passage
1
Parameter setting mode
Equipment in the 4500 series
Structural dimension
109 x 23,5 x 104 mm
Application industry
Whole industry
