Specifications
Series :
4000
Features :
A signal transmitter
Mounting Type :
Open mounting
Description :
Signal transmission, Multi-purpose signal transmitter
Model Number :
4000series
Type :
Signal transmission
Place of Origin :
Beijing, China
Brand Name :
PR electronics
Usage :
Signal conversion, signal protection
Theory :
Multi-purpose signal transmitter
Output :
0-20mA or 4-20mA or 0-10v
Accuracy :
±1°C
Termination Style :
PC Pins
Operating temperature range :
-50-120℃
Connector :
terminal
Power supply :
Ac or DC
MOQ :
5 pieces
Price :
Negotiable
Description
PR Temperature Sensors Analog 4114 4116 4104 Switching 4225 AC DC 4179 Frequency Signal Includes Relay Output 4184
Products Description
Model number
4116
place of origin.
Denmark
brand
PR electronics
Feature
A signal transmitter
Input:

mA, measuring range/minimum range
0... 23 mA / 16 mA
V, measuring range/minimum range
0... 12 VDC / 0.8 V
RTD, measuring range/minimum range
- 200... +850°C / -
Lin.R, measuring range/minimum range
0... 10000 Ω / -
potentiometer
10 W... 100 kW
Sensor connections, cables
RTD 2-wire, 3-wire, 4-wire
TC type
BEJKLNRSTUW3W5Lr
Cold-end compensation
Internal/external
Reference voltage / 2-wire power supply
- / 16 VDC
Output:

mA, signal range/minimum range
0... 23 mA / 16 mA
Load (@ current output)
≤ 800 W
V, signal range/minimum range
0... 10 VDC / 0.8 VDC
Load (@ voltage output)

relay
2 x SPST, AC: 500 VA
Technical specifications:
Ambient temperature
- 20... +60°C
Supply voltage, general purpose, AC/DC
21.6... 253 V/19.2... 300 V
Maximum power consumption
2.5W
Isolation voltage, test/work
2.3 kVAC / 250 VAC
Response time
< 400 ms
Signal dynamic range, input/output
24 bit / 16 bit
precision
< Measuring range of ±0.1%
Temperature coefficient
< ±0.01% of the range / °C
NAMUR
NE21, NE43
passage
1
Parameter setting mode
Equipment in the 4500 series
Structural dimension
109 x 23,5 x 104 mm
Application industry
Whole industry
