ABS Plastic Formwork Reusable Concrete Molding Construction Building Supplier
ABS Plastic Formwork Reusable Concrete Molding Construction Building Supplier
Specifications
Certification :
ROHS
Density :
1.03g/cm³-1.28g/cm³
Price :
US $55.00 - 70.00/ Square Meter
Packaging Details :
Bundled / Tied in bundles/Optimization of container loading
Maximum billet thickness :
300mm
colour :
cyan
Supply Ability :
1000 piece in 10 days
Operating temperature :
-20℃to +80℃
Payment Terms :
T/T
Maximum load pressure :
60KN/sqm for wall & 80KN/sqm for column
Delivery Time :
10-30 workday
Surface hardness :
94
Place of Origin :
Hebei,China
weight :
14kg/sqm
MOQ :
50 piece
Maximum size :
1.2*0.6m
Brand Name :
WKS
Product name :
Modular Plastic Formwork
Customize or not :
Available in custom or standard sizes
Description
ABS Plastic Formwork Reusable Concrete Molding Construction Building Supplier
Best Custom ABS Plastic Formwork - Lightweight, 80+ Reuses & Plaster-Free Concrete Forming
Product Overview

The ABS Plastic Formwork is an innovative concrete forming system manufactured from high-strength engineering-grade ABS polymer. Designed with a modular interlocking system, it enables rapid assembly and dismantling without release agents or specialized tools. Compared to traditional plywood or steel formwork, ABS formwork offers superior reusability (80-100+ cycles), excellent corrosion resistance, and 100% recyclability - making it a cost-effective and environmentally sustainable choice for construction projects.

Key Advantages
  • Lightweight Design - Panels weigh only 12-15 kg/m²; single-worker handling without crane assistance
  • High Reusability (80-100+ cycles) - Dramatically lowers cost per use compared to plywood (3-5 uses)
  • Plaster-Free Finish - Smooth concrete surface after stripping; no release agent required
  • Waterproof & Corrosion-Resistant - Ideal for underground structures and humid environments
  • Eco-Friendly - 100% recyclable; supports green building certifications
  • Easy Maintenance - Clean with water or compressed air; no rust or rot concerns
Customization Capabilities

All products support project-based customization:

  • Panel sizes: 1200×600mm, 600×300mm (custom available)
  • Panel thickness: 75-85mm (ribbed design)
  • Material grade: ABS or ABS + glass fiber reinforcement
  • Color options available
  • Full accessory sets: nylon locking handles, pins, corner panels
Technical Specifications
Parameter Specification
Material ABS (Acrylonitrile Butadiene Styrene)
Panel Size 1200×600mm, 600×300mm
Panel Thickness 75-85mm (ribbed)
Weight 12-15 kg/m²
Reuse Cycles 80-100+ times
Load Capacity 50-60 kN/m²
Connection Nylon locking handles + pins
Surface Finish Smooth (plaster-free)
Applications

Residential and commercial wall/slab construction, column and beam formwork, underground foundations and water-retaining structures, tunnel and bridge infrastructure projects.
