Ultra high power 300W N female circultor 1.2ghz 1.5ghz drone signal base station jammer module
Ultra high power 300W N female circultor 1.2ghz 1.5ghz drone signal base station jammer module
Ultra high power 300W N female circultor 1.2ghz 1.5ghz drone signal base station jammer module
Ultra high power 300W N female circultor 1.2ghz 1.5ghz drone signal base station jammer module
Ultra high power 300W N female circultor 1.2ghz 1.5ghz drone signal base station jammer module
Ultra high power 300W N female circultor 1.2ghz 1.5ghz drone signal base station jammer module
Specifications
Brand Name :
TX TELSIG
Model Number :
TXPD 300W
Certification :
SGS, ISO9001
Place of Origin :
China
MOQ :
1
Price :
Negotiation
Payment Terms :
T/T,Paypal,L/C,D/A,D/P,Etc.
Supply Ability :
5000pcs/per month
Delivery Time :
2 work days
Packaging Details :
Durable Case or Customized
Name :
300W jamming module
Frequency :
Customized
Voltage :
28-32V
Size :
500-1000 meter
Weight :
1143g
Work Temperature :
-40~+65
Description

Ultra high power 300W N female circultor 1.2ghz 1.5ghz drone signal base station jammer module

TXPD 300W is a ultra high power about 300W , the drone signal blocker jammer can disable the 90% drone FPV in the market .The frequency band can customized that wanted to block. The shielding radius around 500-1000 meters, the jamming distance will be varied depending on the antenna and the real environment .

Because this jammer has 300W output ,Therefore this module can support high-powered drones to intercept signal base stations. Capable of intercepting drones over a wide range.Welcome to ontact us with your requirements and we will help to design the most suitable plan for you.

TXtelsig is the leading manufacturer to design and produce signal jamming and wireless coverage product with professional and experienced research and development teams. We have the strength to provide you with the most cost-effective products and plan.

Specifications:
Output Power:300W
Shielding Radius: Up to 500-1000 meters
Power supply: 28-32V
Connector : N type
Dimension:180x 99 x 30mm (without antenna)
Weight: 1143g

No. Item Data Unit
1 Frequency 1.5 G
2 Test voltage 28 V
3 Current 16-20 A
4 Output 200 W
5 Gain 53 dB
6 Output stability 2 dB
7 Connector N / male
8 Output connector VSWR ≤1.40 (No power and VNA test)
9 Power supply wire Red+Black wire
10 Enable Control High ON Low Off
11 Out shell Size 180*99*30 mm
12 Color Silver mm
13 Weight 1143 g
14 Work Temperature -40~+65 ℃
15 Out shell material Aluminum
16 Vibration need Car load OK

Notes for jamming distances:

The jamming distances we mentioned on website are for customer's reference only. The actual jamming distance will be varied depending on the signal strength and the use location and if full charges, etc.

Power supply better carry about 28V 25A when itself 20A for its stable work

Heat dissipation measure is necessary including the thermal glue, suitable-size heat sink and cooling fans

Antenna or Load must be firstly connected before the power supply is ON or it will be short wire

Package contents:

Ultra high power 300W N female circultor 1.2ghz 1.5ghz drone signal base station jammer moduleUltra high power 300W N female circultor 1.2ghz 1.5ghz drone signal base station jammer moduleUltra high power 300W N female circultor 1.2ghz 1.5ghz drone signal base station jammer module

Ultra high power 300W N female circultor 1.2ghz 1.5ghz drone signal base station jammer module
