China supplier 5km outdoors drone detection Blacklist and whitelist safety protection
China supplier 5km outdoors drone detection Blacklist and whitelist safety protection
China supplier 5km outdoors drone detection Blacklist and whitelist safety protection
China supplier 5km outdoors drone detection Blacklist and whitelist safety protection
China supplier 5km outdoors drone detection Blacklist and whitelist safety protection
China supplier 5km outdoors drone detection Blacklist and whitelist safety protection
Specifications
Brand Name :
TXtelsig
Model Number :
TXTC005
Certification :
SGS, ISO9001
Place of Origin :
China
MOQ :
1
Price :
Negotiation
Payment Terms :
T/T, L/C, paypal, etc.
Supply Ability :
10000
Delivery Time :
5-8 days
Packaging Details :
Box with PE Foam
Product name :
Drone detection
Frequency :
0.7-6.3GHz/ 2.4-2.5GHz/5.15-5.95GHz
Jamming distance :
5km
Detection angle :
360°
Weight :
25kg
Protection grade :
IP65
Description

China supplier 5km outdoors drone detection Blacklist and whitelist safety protection

This detector boasts an impressive 5km detection range—far exceeding standard consumer-grade detectors. Whether in open fields, industrial complexes, or large event venues, it can identify approaching drones at an early stage, providing ample time for security personnel to assess the situation, issue alerts, and take response measures.

Our detector addresses this by covering an extensive frequency spectrum of 700-6300MHz—a range that encompasses most common drone communication and control bands. This product features 360° omni-directional detection capability. Its specially designed antenna array ensures uniform signal reception across all angles.

Feature

  • 700-6300MHz full air space detection
  • Detecting distance around 5km(Increasing antenna gain can extend the detection distance)
  • Can extract drone signals under noise interference level (SNR -10 ~ -15dB)
  • Analysis DJI FPV date Including pilot location, blacklist and whitelist,connect to Bluetooth to update the firmware
  • Provide FPV drone video image output,connect to Bluetooth to update the firmware

Application

It is used to cooperate with the portable drone interference setting to compensate for the untimely detection of drones during work; It is used for mobile duty of police personnel and vehicles, and detects surrounding drones as soon as possible.By locating the position of drone pilots, we can effectively combat illegal flying. By analyzing DJI drone data, we can better deal with jamming drones.

Regular detection range 5km(Good radio environment)
Detection frequency bands 0.7-6.3GHz/ 2.4-2.5GHz/5.15-5.95GHz
Identify Type

FPV Simulation Image Transmission

OFDM HD Image Transmission
Detection angle 360°
Sensitivity

Better than -96dBm (FPV signal Bw=6MHz)

Better than -90dBm (OFDM signal Bw=20MHz)
Detection distance

＞2km (OFDM) ＞4km (FPV 5.8G/2W)

(The measured reliable distance when using a 2dBi gain receiving antenna. The actual antenna gain increases by 6dB, and the detection distance can be doubled.)
UART Parameters 115.2kbps/TTL3~5V compatible
Power supply DC 4.75 ~36V
Power consumption ＜3.5W
Weight 25kg
Volume 330mm x 330mm x 330mm
Protection grade IP65
Working temp -40 ~ +70℃

China supplier 5km outdoors drone detection Blacklist and whitelist safety protectionChina supplier 5km outdoors drone detection Blacklist and whitelist safety protectionChina supplier 5km outdoors drone detection Blacklist and whitelist safety protection
