CSD17304Q3

FEATURES

• Optimizedfor5VGateDrive

• UltralowQgandQgd

• LowThermalResistance

• AvalancheRated

• PbFreeTerminalPlating

• RoHSCompliant

• HalogenFree

• SON3.3-mm×3.3-mmPlasticPackage

APPLICATIONS

• NotebookPointofLoad

• Point-of-LoadSynchronousBuckin

Networking,Telecom,andComputingSystems

DESCRIPTION

The CSD17304Q3 is a 30V N-channel NexFET™ power MOSFET from Texas Instruments (TI), featuring an advanced SON 3.3x3.3mm package. Designed for high-current, high-efficiency power conversion, its ultra-low Rds(on) (2.2mΩ) and 60A continuous current capability make it ideal for automotive electronics, industrial power systems, and motor drives.

✔ 80% smaller than TO-220 packages
✔ 60% lower conduction loss (vs. 5mΩ MOSFETs)
✔ Supports 1MHz PWM switching

INFORMATION

Category
Mfr
Texas Instruments
Series
NexFET™
Packaging
Tape & Reel (TR)
Cut Tape (CT)
Digi-Reel®
Part Status
Active
FET Type
N-Channel
Technology
MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)
30 V
Current - Continuous Drain (Id) @ 25°C
15A (Ta), 56A (Tc)
Drive Voltage (Max Rds On, Min Rds On)
3V, 8V
Rds On (Max) @ Id, Vgs
7.5mOhm @ 17A, 8V
Vgs(th) (Max) @ Id
1.8V @ 250µA
Gate Charge (Qg) (Max) @ Vgs
6.6 nC @ 4.5 V
Vgs (Max)
+10V, -8V
Input Capacitance (Ciss) (Max) @ Vds
955 pF @ 15 V
FET Feature
-
Power Dissipation (Max)
2.7W (Ta)
Operating Temperature
-55°C ~ 150°C (TJ)
Grade
-
Qualification
-
Mounting Type
Surface Mount
Supplier Device Package
8-VSON-CLIP (3.3x3.3)
Package / Case
8-PowerTDFN
Base Product Number
CSD17304

Drawing
